Package Mechanical Specifications
3.6

Processor Mass Specification

The typical mass of the processor is 35g. This mass [weight] includes all the
components that are included in the package.
3.7

Processor Materials

Table 3-3
Table 3-3.

Processor Materials

Integrated Heat Spreader (IHS)
3.8

Processor Markings

Figure 3-4
identification of the processor.
Figure 3-4.

Processor Top-side Markings

Datasheet
lists some of the package components and associated materials.
Component
Substrate
Substrate Lands
shows the top-side markings on the processor. This diagram is to aid in the
INTEL
BRAND
SLxxx [COO]
SPEED/CACHE/INTC/FMB
[FPO]
Material
Nickel Plated Copper
Fiber Reinforced Resin
Gold Plated Copper
©'07 PROC#
M
e
4
35
