Back Panel Features
A.
Power supply
B.
Location for installing optional redundant
power supply
C.
I/O Ports. See
The diagram and table show the back panel connectors and LEDs. For information about
the LEDs, see
8
C
Figure 6 on page 9
Figure 5. Server System Back
®
"Intel
Light-Guided Diagnostics" on page
A
B
E
D
AF001485
D.
PCI card area
E.
Rear Serial B Connector (optional)
15.
Intel® Server System SC5400RA User's Guide
