Figure 4. Intel Local Control Panel - Intel S7000FC4UR - Server System - 0 MB RAM Product Manual

Item
I
J
K
L
M
8
Feature
System status / Green / amber LED for system status. See
fault LED details.
LED
Off
Green on
Green blink
Amber blink
Amber on
LAN1, LAN 2 Green LEDs
Status LEDs
LAN1 shows status of either LAN port on the server board
LAN2 shows status of either LAN poor on the I/O riser board
LED State
Off
Blinking
Hard drive status Green / amber LED that indicates hard drive activity and faults
LED
LED State
Green on
Green blink
Amber on
Amber slow
blink (~1 Hz)
Amber fast
blink (~2.5
Hz)
System reset Resets the system
button
Figure 4. Intel
Description
System State
Not ready
Ok
Degraded
Non-fatal
Fatal
LAN State
Idle
Active
Drive State
SAS drives are installed and functioning correctly
NOTE: LED may blink if all drives are active at
the same time.
SATA drives are installed and active
Drive / slot failure
Predictive hard drive / slot failure or rebuild in
process
Rebuild interrupted or rebuild on empty slot
®
Local Control Panel
Intel® Server System S7000FC4UR Product Guide
Table 3 for additional
Definition
AC power off
System is booted and
ready to operate
System is in a degraded
state
System is likely to fail
System has failed
Activity
No activity
Access
