Intel® Server System S7000FC4UR Product Guide
Item
G
Hard Drive 0
H
Hard Drive 1
I
Hard Drive 2
J
Hard Drive 3
K
Hard Drive 4
L
Hard Drive 5
M
Hard Drive 6
N
Hard Drive 7
Figure 48. SAS Backplane Connectors (Drive Bay Side)
Item
A
Control panel connector
B
Main board connector
C
SAS backplane board connector
Figure 49. Front Panel Board Component Locations
Description
A
B
C
AF002262
Description
89
