Hardware Installations and
Upgrades

Before You Begin

Before working with your server product, review the safety and ESD information at the
beginning of this manual and in the appendices.

Tools and Supplies Needed

•
Phillips
•
1/4-inch nut driver
•
Needle-nosed pliers
•
Ant-static wrist strap and conductive foam pad (recommended)

Installation Guidelines

Before installing options:
1. Observe the safety and ESD information at the beginning of this manual and in the
appendices.
2. Remove the compute module from the chassis; before doing so, you must first shut
down the operating system and turn off the compute module. You do not have to shut
down the chassis.
3. Blue on a component indicates a touch point, where you can grip the component to
install or remove it from the server.
4. Green on a component indicates that the component may be hot-swapped. See the
instructions included with the hot-swap component for a complete list of installation
or removal steps.
Removing and Installing an Intel® Compute Module
MFS5000SI

Removing a Compute Module from the Server System

1. Observe the safety and ESD information at the beginning of this manual and in the
appendices.
2. If the compute module is operating, shut down the operating system and power it
down.
Intel® Compute Module MFS5000SI User Guide
(cross head) screwdriver (#1 bit and #2 bit
*
7
