Installing the Cisco 1113 in a Rack
Figure 3-9
Repeat this process with the other rail and rack assembly.
Step 3
Note

Sliding Chassis On the Rack

See
Step 1
This allows the chassis rail mount to slide on to the rail.
Installation Guide for Cisco Secure ACS Solution Engine 4.1
3-8
Attaching Rail to a Circular-Peg Rack
Leaving some play between the bracket and the rail until you install the rail into the rack will
make affixing the rail to the rack easier. After the rail is attached to the rack, you can tighten the
screws.
Figure 3-10. On the chassis rail mount, slide and hold the purple tab in the direction of the arrow.
