Installing the Cisco 1113 in a Rack

Table 3-1
Task
Verify initial configuration
Configure ACS SE to provide AAA
services
Installing the Cisco 1113 in a Rack
Before installing the Cisco 1113 in a rack, read
familiarize yourself with the proper site and environmental conditions. Failure to read and follow these
guidelines could lead to an unsuccessful installation and possible damage to the system and components.
Perform the steps below when installing and servicing the Cisco Secure ACS SE.
The rack must be properly secured to the floor, to the ceiling or upper wall, and where applicable, to
adjacent racks. The rack should be secured using floor and wall fasteners and bracing specified or
approved by the rack manufacturer or by industry standards.
When installing and servicing the ACS SE:
•
•
•
•
•
•
See
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special
Warning
precautions to ensure that the system remains stable. The following guidelines are provided to
ensure your safety:
•
•
•
Installation Guide for Cisco Secure ACS Solution Engine 4.1
3-2
Quick Reference (continued)
Disconnect all power and external cables before installing the system.
Install the system in compliance with your local and national electrical codes:
United States: National Fire Protection Association (NFPA) 70; United States National
–
Electrical Code.
Canada: Canadian Electrical Code, Part, I, CSA C22.1.
–
Other countries: If local and national electrical codes are not available, see IEC 364, Part 1
–
through Part 7.
Do not work alone under potentially hazardous conditions.
Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.
Do not attempt to install the ACS SE in a rack that has not been securely anchored in place. Damage
to the system and personal injury may result.
Due to the size and weight of the computer system, never attempt to install the computer system by
yourself.
Precautions for Rack-Mounting, page 2-8
This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest
component at the bottom of the rack.
If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in
the rack.
Chapter 3 Installing and Configuring Cisco Secure ACS Solution Engine 4.1
References
Verifying the Initial Configuration,
page 3-15
Next Steps, page 3-17
Preparing Your Site for Installation, page 2-6
for additional safety information on rack installation.
to
