Replacing the separation
roller tires
Changing the separation
pad
5-16
To replace the separation roller tires:
1. Remove the separation roller as previously directed.
2. Replace each tire by sliding the tire off the core.
3. Install each new tire by gently stretching it over the core.
IMPORTANT: Do not overstretch the tire; it may tear.
4. Reinstall the separation roller as previously directed.
Change the pre-separation pad when the frequency of double-fed
documents increases.
1. Open the swing out door.
2. Lift the roller cover.
3. Remove the pre-separation pad.
4. Install the new pre-separation pad. Be sure it snaps into place.
5. Lower the roller cover.
6. Close the swing out door.
A-61169 January 2005
