External components

Operator control
Side guides
Elevator tray

Back of scanner

A-61169 January 2005
See the illustration below for the location of the external components of
the scanner.
Output tray
panel
Feed module
SCSI Connector
Top cover
Swing out door
Bi-fold door
Power switch
Gap release lever
Feeder extensions
Power cord
connector
1-5
