Page 1 Series Scanners Image Processing Guide User’s Guide A-61510...
Page 2 ISIS is a registered trademark of Pixel Translations, a division of Input Software, Inc. Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Page 3 Please refer to your application vendor’s documentation for specific information. Four configurations of the i800 Series Scanners are available. Kodak i810 Scanner (bi-tonal) throughput speeds up to 120 ppm.
Page 4 About this manual A-61510 January 2005 This manual provides the following: Chapter 1, Introduction – includes a brief summary of the Kodak i800 Series Scanners, a list of features available for each scanner and the support drivers. Chapter 2, Best Practices – includes information to use when setting up...
Page 5 Image outputs FB.tif (front bi-tonal) A-61510 January 2005 i800 Series Scanners can return bi-tonal, grayscale or color images to the host. Below is a description of the valid combinations. All i800 Scanners are duplex scanners. This means both the front and the rear side of each document may be captured.
Page 6 FG.jpg (front grayscale) A-61510 January 2005 Another example of a simultaneous output where all four images are returned to the host would create the following four files: Front grayscale: FG.jpg. This image file represents the contents of the front side of the document using 8-bits per pixel. Front bi-tonal/binary: FB.tif.
Page 7: Best Practices
This chapter provides you with recommendations for program logic, which will allow you to interact efficiently with the i800 Scanner. This high-level information is not intended to be used as a coding guide. The following information is provided in this...
Page 8 Scanner setup A-61510 January 2005 To set up the scanner: 1. Set up your scanner operating conditions: simplex/duplex starting image address image order lamp timeout transport timeout transport timeout response length detection status and response multi-feed detection status and response...
Page 9 New imaging parameters are sent from the host. 4. It is recommended that you calibrate the scanner. For procedures on how to do this, see the Kodak i800 Series Scanners, User’s Guide. 5. Prepare documents according to the instructions found in the Kodak i800 Series Scanners, User’s Guide.
Page 10 Since one or more errors may be pending at any time, current errors are reported first. A deferred error results from an error condition within the scanner, such as a document jam. Deferred errors that may have occurred are reported after current errors.
Page 11 NOTE: The scanner cannot determine exactly which images were affected by the error and which images were not. If an error occurs that disables the scanner, the host can continue to read images from the image buffer without enabling the scanner.
Page 12: Transfer Order
The host application is responsible for determining the order in which the scanner returns images. Front images must always be retrieved before rear images. This job stream is available for all i800 Series Scanners. 1. Prepare documents. 2. Start the scanner to do bi-tonal duplex scanning (front bi-tonal and rear bi-tonal).
Page 13 End loop This job stream is available for i820 and i840 Series Scanners. 1. Prepare documents. 2. Start the scanner to do dual stream simplex scanning (front bi-tonal and front color). 3. Setup the scanner to retrieve bi-tonal images first.
Page 14 This job stream is available for i820 and i840 Series Scanners. 1. Prepare documents. 2. Start the scanner to do dual stream duplex scanning (front bi-tonal, front color, rear bi-tonal and rear color). 3. Setup the scanner to retrieve bi-tonal images first.
Page 15 (color/grayscale). The example illustrates using patch type 4 in the same way which the “color patch” is utilized on the Kodak Digital Science Scanner 3590C where it starts using bi-tonal. 1. Prepare documents with a patch Type 4 before and after any color/grayscale documents.
Page 16 A-61510 January 2005 This section provides recommendations for application logic associated with scanner jam and fault recovery. If your scanner is enabled and you are polling when a document jam or other fault occurs, use the following procedure to restart scanning.
Page 17: Bar Code Recognition
This section provides general information about bar code recognition and read rates. Unlike previous high-volume scanners from Kodak, the i800 Series Scanners do not include a bar code accessory. Bar code functionality is now the responsibility of the host system. The main imaging parameter, which may affect bar code read rates, is resolution.
Page 18 Starting image address/ next image address A-61510 January 2005 Unlike previous high-volume scanners from Kodak, the i800 Series Scanners moved all image address functionality to the host. This includes index format, starting image address, image address format and level rules.
Page 19: Indexing Schemes
Indexing schemes A-61510 January 2005 Documents are scanned to record the information in an easily accessible form. The scanner offers the following indexing schemes: Single level Two level Two level offset Three level Three level offset Single level indexing When using single level indexing, the image address assigned to...
Page 20: Two Level Indexing
A-61510 January 2005 Two level indexing When using two level indexing, the image address assigned to each document is defined as follows: Field D (Level 1) defined as having a field length greater than 0. Field C (Level 2) defined as having a field length greater than 0. Fields B and A may be defined as fixed fields if desired.
Page 21: Chapter 2 Image Address 02 Header
A-61510 January 2005 Two level offset indexing When using two level offset indexing, the image address assigned to each document is defined as follows: Field D (Level 2) defined as having a field length greater than 0. Fields C, B and A may be defined as fixed fields if desired. For example, if you scan a book with 2 chapters (Chapter 1 has 40 pages and Chapter 2 has 60 pages), the image address has been defined:...
Page 22: Three Level Indexing
A-61510 January 2005 Three level indexing When using three level indexing, the image address assigned to each document is defined as follows: Field D (Level 1) defined as having a field length greater than 0. Field C (Level 2) defined as having a field length greater than 0. Field B (Level 3) defined as having a field length greater than 0.
Page 23 The header page for Section 2 is assigned image address 2.00.000. The header page for Chapter 1 of the section is assigned image address 2.01.000. The pages within the chapter are assigned image address(es) 2.01.001 through 2.01.120. Any one of the pages may later be located and retrieved using its unique image address.
Page 24: Three Level Offset Indexing
A-61510 January 2005 Three level offset indexing When using three level offset indexing, the image address assigned to each document is defined as follows: Field D (Level 2) defined as having a field length greater than 0. Field C (Level 3) defined as having a field length greater than 0. Fields B and A may be defined as fixed fields if desired.
Page 25 If you do not set or change the document level using one of the methods listed, the document level will be set automatically based upon the level rules (i.e., Level 2 is followed by Level 1, etc.) defined during scanner setup. 2-19...
Page 26 Level instruction: Operator selects Level III using the Level icon on the OCP or uses a patch III document (Level II and I documents are generated automatically using the level to follow level rules). Level Instruction: Operator selects Level II using the Level icon on the OCP or uses a patch II document (Level 1 documents are generated automatically using the level to follow level rules).
Page 27 Level rules A-61510 January 2005 Unlike previous high-volume scanners from Kodak, the i800 Series Scanners moved the responsibility for defining and controlling level rules to the host. Level rules are an automated way to control document image addressing based on the level of the previous document.
Page 28: Electronic Color Dropout
Distance from lead edge Can print to within ½-inch of the trial edge. The i800 Series Scanners provide the ability to create dropout images without changing lamps. The application has the ability to select red, green and blue dropout functionality. Only one color can be dropped out at a time.
Page 29 Two categories of performance are provided or each color: Colors that can be completely dropped out and colors that are very close to complete dropout. These values were established by using standard Pantone Matching System® Colors guide (uncoated, 175-line screen). If the background of the document you are using is not bright white the results may vary.
Page 30 Red dropout 100 U 114 U 101 U 115 U 102 U 116 U Yellow U 120 U 106 U 121 U 107 U 122 U 108 U 123 U 109 U 1205 U 113 U 1215 U 130 U 1505 U 136 U Orange...
Page 31 122 U 1355 U 128 U 141 U 100 U 230 U 101 U 236 U 102 U 2365 U 106 U 243 U 217 U 250 U 223 U 251 U Yellow U 2572 U 2375 U 2563 U 244 U 2567 U 257 U...
Page 32 Image header information A-61510 January 2005 An image header is associated with every image captured by the scanner. Following is a list of information available in the image header. Image length size of the image. Image identifier indicates whether the image is front bi-tonal, rear bi-tonal, front color or rear color.
Page 33 A severe skew angle may result in no deskew being performed. If the scanner is unable to determine a skew angle, the image will not be deskewed. The skew angle field of the image header will be set to 0.
Page 34 The host application controls the setting of the starting value for this counter. Patch Type the scanner indicates if a patch type was recognized on the document in the image header. If no patch type is recognized, or if patch reading is not enabled, this value will be zero.
Page 35: Zone Processing
This feature may be used in conjunction with auto cropping. Following is an example of producing a color zone. Original Bi-tonal image 1. Prepare documents. 2. Start the scanner to do dual stream simplex scanning (front bi-tonal and front color). Relative Cropping 2-29...
Page 36 A-61510 January 2005 3. Setup the scanner to retrieve bi-tonal images first. 4. Setup front bi-tonal to be auto cropping. 5. Setup front color to be relative cropping. 6. Enable the scanner and start polling. Loop Read front bi-tonal image header...
Page 37: Programmable Keys
Programmable keys A-61510 January 2005 There are three programmable keys on the Operator Control Panel of the scanner. These keys can be assigned functions by the host application. Programmable keys are available for use by the operator when the scanner is enabled. The Operator Control Panel displays the numbers 1 through 3.
Page 38: Patch Reading
PC or Operator Control Panel intervention. All documents with patch codes are imaged and cannot be automatically deleted by the scanner. A patch code can change the IA level of the document that the patch code occurs on (or the following document in the case of a Transfer patch).
Page 39 (bi-tonal) to the alternative image stream (color). This logic is performed inside the scanner. Images of the toggle patch sheet will not be returned to the host unless you also enable patch reading and select the Type 4 patch.
Page 40 See the section entitled “Controlling image order” earlier in this chapter for examples on how to use additional patches. Batching provides a way for the scanner to perform a specific function after scanning a designated number of documents at a particular IA level.
Page 41: Using The Twain Data Source
\twain_32\kodak\kds_i800 which documents this TWAIN functionality. The file ramscan.txt in the same directory includes the information you need to use the TWAIN Data Source for RAM scanning which simulates an i800 Series Scanner in order for you to begin development work without a physical scanner.
Page 42 1. Select Start>Run or select Programs>Kodak>Document Imaging>Scan Validation Tool. The Scan Validation Tool dialog box will be displayed. 2. Select TWAIN and Kodak Scanner: i800. If you are using the ISIS driver see Chapter 4. 3. Click OK. 4. Double-click the Scanner icon to access the Kodak Scanner...
Page 43: Scan Validation Tool Dialog Box
Scan Validation Tool dialog box A-61510 January 2005 The Kodak Scan Validation Tool dialog box allows you to verify scanner functionality through the TWAIN Data Source. Button Description Displays the Users Interface for the selected either the ISIS Driver or TWAIN Data Source.
Page 44: Kodak Scanner Properties Dialog Box
Scan Validation Tool session. The Kodak Scanner Properties dialog box consists of 12 tabs. Each tab will be described within this chapter. Click on each tab to set all the desired values. You do not have to click OK until you have made all selections on all of the tabs.
Page 45: Buttons On The Kodak Scanner Properties Dialog Box
Buttons on the Kodak Scanner Properties dialog box A-61510 January 2005 Following are descriptions of the buttons located at the bottom of the dialog box. Defaults when you select Defaults, the message Reset all values to factory defaults? will be displayed. Clicking Yes will reset all values on all tabs to the factory defaults.
Page 46: The Imaging Tab
If you have an i810 or i830 scanner, only Front Bi-tonal and Rear Bi-tonal will be displayed. If you have an i820 or i840 scanner, Front Color, Rear Color, Front Bi-tonal and Rear Bi-tonal will be displayed. For more information about these selections see the section entitled, “Image...
Page 47 Binarization these settings effect the bi-tonal image. Available settings are: iThresholding: selecting iThresholding allows the scanner to dynamically evaluate each document to determine the optimal threshold value to produce the highest quality image. This allows scanning of mixed document sets with varying quality (i.e., faint text, shaded backgrounds, color backgrounds) to be scanned using a single setting thus reducing the need for document sorting.
Page 48 A-61510 January 2005 When Adaptive Thresholding is selected, Contrast values may range from 1 to 100. A Contrast value of 100 is considered fully adaptive thresholding. Fixed thresholding ATP disabled Fixed Processing used for black-and-white and other high contrast documents. A single level is set to determine the black-and-white transition.
Page 49 A-61510 January 2005 Noise Filter occasionally small dots or specks appear in the background of a scanned image. These specks increase file compression size and usually contain no image information. Using the Noise Filter on documents containing very fine detail (e.g., the dot on an "i"...
Page 50 A-61510 January 2005 Contrast % sets the image contrast by adjusting the difference between black and white, thereby making an image sharper or softer. In a low-contrast setting, the difference between black and white is small, so the image is softer. In a high-contrast setting, the difference between black and white is large, so the image is clearer.
Page 51 (0 to 255) in the Threshold text box. Scan the document to check the threshold. NOTE: This setting works with the Contrast setting. A Contrast setting of 0 causes the scanner to use fixed thresholding. A Contrast setting of 100 causes the scanner to use fully-adaptive thresholding.
Page 52 This is the same functionality, which is available on the Kodak Digital Science 3590C Scanner. Select Off, Front Side or Both Sides.
Page 53 Choose a resolution value from the drop down list. The default is 200 dpi. Available resolutions are: Color Scanner i820 — 100, 150, 200 Scanner i840 — 100, 150, 200, 300 indicates the scanning resolution, 3-13...
Page 54 You can chose from six different Kodak default color tables: Pictures, Pictures 2, Text, Text with Pictures, Text with Pictures 2, and Text with Pictures 3. The user can also download and accept custom color tables.
Page 55 You can chose from six different Kodak default color tables: Pictures, Pictures 2, Text, Text with Pictures, Text with Pictures 2, and Text with Pictures 3. The user can also download and accept custom color tables.
Page 56: The Paper Tab
If you have an i810 or i830 scanner, only Front Bi-tonal and Rear Bi-tonal will be displayed. If you have an i820 or i840 scanner, Front Color, Rear Color, Front Bi-tonal and Rear Bi-tonal will be displayed.
Page 57 Cropping values A-61510 January 2005 Cropping allows you to capture a portion of the document being scanned. You can define the cropping area by the x and y offset values, width and length. All cropping options can be used with color and bi-tonal images and are front/rear and dual stream independent.
Page 58 For relative cropping this is the distance from the left edge of the document to the left edge of the zone.
Page 59 Length — the length of the scanning area. If Overscan is not selected, the scanner will not continue capturing beyond the trail edge of the document. For example, if you setup the scanner for 8 ½” x 11” portrait-fed documents, and you scan an 8 ½ x 4” document, the scanner will return an 8 ½...
Page 60: The Compression Tab
If you have an i810 or i830 scanner, only Front Bi-tonal and Rear Bi-tonal will be displayed. If you have an i820 or i840 scanner, Front Color, Rear Color, Front Bi-tonal and Rear Bi-tonal will be displayed.
Page 61 Compression is None Compression (Source Will Decompress) and None. If you select JPEG, the images from the scanner are compressed. The TWAIN driver will decompress and return uncompressed images to the host. If you select None, the images from the scanner are uncompressed.
Page 62: The Dropout Tab
(through OCR and ICR technology) read pertinent data without interference from the lines and boxes of the form. The i800 Series Scanners can dropout either red, green or blue. The Dropout tab allows you to select the desired dropout color, alter the filter threshold and background.
Page 63 Background this value will be substituted in the grayscale (pre-thresholded) image for the color being removed. Therefore, this value should be higher than the threshold value selected on the Imaging tab for this pixel to become the background color. For example, if you are scanning a white document with a green form and you have selected a bi-tonal threshold value of 127, you should pick an electronic color drop-out background value greater than 127 so the substituted pixel will...
Page 64 The Image Address tab A-61510 January 2005 Image addressing provides better document management opportunities. Image addressing is used for document tracking, batch control and image management. The Image Address tab allows you set an image address starting point and increment the image address according to how the application is setup.
Page 65 Image Address Template area Each field may be a maximum of 9 characters. The total image address cannot exceed 27 characters (30 with 3 delimiters). The i800 Series Scanners have more options available for image addressing schemes with the following guidelines: You may define from 0 to 4 fixed fields.
Page 66 1 field. Level to Follow Level Rules These are the rules the scanner will follow to set the next image address level if there are no other inputs. For example, patch sheet or end of batch processing. You will have to define a level to follow level for each of the level fields you defined in your image address template area.
Page 67 The Batch tab Batch Control area A-61510 January 2005 Batching is the operation of counting pages or documents. The Batch Control area defines the level to count the number of documents in the batch and any actions to be taken at the beginning and end of a batch.
Page 68 Patch Control area A-61510 January 2005 Batch End Function defines the action to be taken after processing the last document in the batch. Options are Stop Feeder, End of Job, Start New Batch or No action. The Patch Control area provides choices of what patch type to recognize.
Page 69 Patch Confirmation tone signal that a patch has been recognized. The default is no confirmation tone. See the Kodak publication A-61599, Patch Code Information for Kodak Document Scanners for complete information. (Do not use these patches for production – they are not to spec) (Do not use these patches for production –...
Page 70 Button Control area A-61510 January 2005 This section is used to assign actions the operator uses from the Operator Control Panel. Function Key #1, Function Key #2 and Function Key #3. Available functions are: End-of-Job Terminate Batch Skip Multi-feed Detection Skip Printing Skip Patch Recognition Lower Elevator...
Page 71: The Multifeed Tab
The Multifeed tab A-61510 January 2005 Multi-feed Detection aids in document processing by detecting documents that may go through the feeder overlapped. Multi-feeds can happen due to stapled documents, adhesives on documents, or electrostatically charged documents. 3D Multi-feed Detection combines ultrasonics (amplitude and phase) with physical length detection to virtually eliminate the chance of loosing data due to multi-feeds.
Page 72 (the scanner will be disabled). Scanning can only be resumed when the scanner is re-enabled from the host. With all options, the scanner will beep if the alarm tone volume is set higher than 0. if this option is not selected, the scanner...
Page 73: The Options Tab
(bi-tonal and color/grayscale) for either side, this option controls the order in which the scanner will return image data. For example, if you are scanning color/grayscale and bi-tonal and you select Bi-tonal Image, the scanner will return the bi-tonal front image, then the front color/grayscale image.
Page 74 Transport Timeout allows you to set a transport timeout value. This value is the amount of time the scanner will wait after the last document enters the transport before the transport timeout action is taken. You can specify a time delay setting from 5 to 300 seconds. The default is 10 seconds.
Page 75: The Printer Tab
The Printer tab Print Template setup A-61510 January 2005 The Document Printer 1 provides a vertical print capability that is programmed to support alphanumeric characters as defined by the host. It supports date, image address, time, document count and custom messages.
Page 76 Counter: this value is used to assign the document count for the next document entering the transport. This value is incremented sequentially by the scanner unless another document count is received from the host. This value is returned in the image header.
Page 77 A-61510 January 2005 Counter Format used to control the width of the document counter. Values range from 1-9. The following choices are available for printing the counter format. Display leading zeros format (e.g., 0009) Suppress leading zeros format (e.g., 9) Compress leading zeros format (e.g., 9) Date Format select one of the date formats: Forward slash (/),...
Page 78: Printing Orientation
Printing orientation A-61510 January 2005 You can select what orientation you want your information to be printed in as well as the location on your document. Font two different character sizes, referred to as Large and Small, are available. Information is printed on each document in one of the two orientations: Comic or Cinema.
Page 79: Horizontal Print Position
A-61510 January 2005 Start position Character top Printing area Paper NOTE: Printing automatically stops 6.3 mm (1/4-inch) from the trailing edge of the document even if the information has not been completely printed. Horizontal Print Position The horizontal print position is set manually in one of the 13 positions on the Document Printer mounting plate.
Page 80: The Setup Tab
SCSI cable. Up-to-date firmware for the i800 Series Scanners will be available from the Kodak website www.kodak.com. NOTE: Downloading firmware should be done by the System Administrator.
Page 81: The Info Tab
Scanner Model, Scanner Configuration, Firmware Revision, Minimum Scan Resolution, Maximum Scan Resolution, Scanner Serial Number, Scanner CPU Date/Time, and the Name and Company of the person who installed the scanner. Scanner Meters shows information about your scanner, such as how...
Page 82: Using The Isis Driver
Pixel Translations, Inc. documentation which documents ISIS functionality. This documentation includes the information you need to use the ISIS Driver for RAM scanning which simulates an i800 Series Scanner in order for you to begin development work without a physical scanner.
Page 83 1. Select Start>Run or select Programs>Kodak>Document Imaging>Scan Validation Tool. The Scan Validation Tool dialog box will be displayed. 2. Select ISIS and Kodak Scanner: i800. If you are using the TWAIN driver see Chapter 3. 3. Click OK. 4. Double-click the Scanner icon to access the Kodak Scanner...
Page 84 Scan Validation Tool dialog box A-61510 January 2005 The Kodak Scan Validation Tool dialog box allows you to verify scanner functionality through the ISIS Driver. Button Description Displays the Users Interface for the selected either the ISIS Driver or TWAIN Data Source.
Page 85: Button Description
A-61510 January 2005 Button Description Opens the image viewer to display one image at a time. Opens the image viewer to display two images at a time. Opens the image viewer to display four images at a time. Opens the image viewer to display eight images at a time.
Page 86: Scanner Settings Dialog Box
NOTE: For the purpose of this manual, all displayed dialog boxes assume the features available on the Kodak i840 Scanner.
Page 87: Buttons On The Scanner Settings Dialog Box
Scan Area dialog box. Copy this function is only available when using the scanner in Duplex mode. The Copy button provides a convenient way to set up the color/grayscale or binary image settings on one side and transfer them to the other.
Page 88 For example, if you are scanning front color/grayscale and front binary and you select Binary First the scanner will return the front binary image, then the front color/grayscale image. Configure highlight the image you want to set up.
Page 89 Choose a resolution value from the drop-down list. The default value is 200 dpi. Available resolutions are: Binary Scanner i810, i820, i830, i840 — 200, 240, 300, 400 indicates the scanning resolution,...
Page 90 Page size and layout A-61510 January 2005 The default paper size is set when a scanner is first selected. You can choose a different paper size using the drop-down list box. NOTE: The Page Size and Page Layout selections also appear on the Area dialog box.
Page 91 A-61510 January 2005 When Adaptive Thresholding is selected, Contrast values may range from 1 to 100. A Contrast value of 100 is considered fully adaptive thresholding. Fixed thresholding ATP disabled Error Diffusion screens photographic areas of a document to simulate gray levels yet sharpens the edges of text. It is recommended that error diffusion be used when a mix of text, graphs, pictures and colors in the documents are being scanned.
Page 92 A-61510 January 2005 Cropping allows you to capture a portion of the document being scanned. All cropping options can be used with color/grayscale and binary images. Front and Rear cropping are independent, however, for dual stream scanning color/grayscale and binary cropping must be the same per side.
Page 93 This option may be used in conjunction with auto cropping where a separate color/grayscale or binary area to be saved is desired. It is very useful in applications where a photograph, signature, embossment or seal appears in a consistent area for an application (you may want that small area in color/grayscale and the rest in binary).
Page 94 Contrast sliding bar to the left or right to achieve the desired Contrast setting. Scan the document to check the contrast. Automatic not available for i800 Series Scanners. Threshold thresholding is used to convert a gray scale image into a binary (1 bit/pixel) image.
Page 95 200 dpi; 80 Threshold; 20 Contrast 200 dpi; 80 Threshold; 100 Contrast Lighten, Normal and Darken are used as quick sets to adjust the threshold. Lighten = 72, Normal = 90 and Darken = 128. A-61510 January 2005 4-14...
Page 96: More Scanner Settings Dialog Box
More Scanner Settings dialog box A-61510 January 2005 Additional image processing values unique to the i800 Scanner are available when you choose the More button on the Scanner Settings dialog box. 4-15...
Page 97 The selections in the Camera area list the available sides (front and back) of an image where you can define individual image processing values. If you have an i810 or i830 scanner, only Front Binary and Back Binary will be displayed. If you have an i820 or i840 scanner, Front Color, Back Color, Front Binary and Back Binary will be displayed.
Page 98 Image Control options A-61510 January 2005 JPEG Quality JPEG compression offers a JPEG quality of Draft, Good, Better, Best, Superior and Sharpen. Draft the smallest file size with draft image quality. Good a larger file size with good image quality. Better a larger file size with better image quality.
Page 99 You can chose from six different Kodak default color tables: Pictures, Pictures 2, Text, Text with Pictures, Text with Pictures 2, and Text with Pictures 3. The user can also download and accept custom color tables.
Page 100 Noise Filter A-61510 January 2005 Occasionally small dots or specks appear in the background of a scanned image. These specks increase file compression size and usually contain no image information. Using the Noise Filter on documents containing very fine detail (e.g., the dot on an "i" in 4-point type) may cause information to be lost.
Page 101 Batch and Patch Code Definition dialog box. This dialog box allows you to define logic associated with automating your scanner’s workflow. The settings in this dialog box do not affect the quality of the image. See the section entitled, “Defining Batch Detection and Patch Code values”...
Page 102 Setting scanner controls A-61510 January 2005 The Scanner Control dialog box allows you to set the following controls: Multi-feed and Ultrasonic detection Transport Control Lamp Saver functionality Function Keys (Programmable keys) 4-21...
Page 103 (the scanner will remain enabled). When an overlap or multi-feed is detected, the scanner stops the feeder, clears the transport of all pages and then the documents can be refed. End Job...
Page 104 Enable Timeout allows you to set a transport timeout value. This value is the amount of time the scanner will wait after the last document enters the transport before the transport timeout action is taken. You can specify a time delay setting from 5 to 300 seconds. The default is 10 seconds.
Page 105 Enabling Lamp Saver extends lamp life and reduces energy consumption. This value is the amount of time (in minutes) the scanner will wait after the last document enters the transport before the lamps will turn off. If enabled, you can specify a time delay setting from 1 to 30 minutes.
Page 106 Enabling and setting Document Printer options A-61510 January 2005 The Document Printer 1 provides a vertical print capability that is programmed to support alphanumeric characters as defined by the host. It supports date, image address, time, document count and custom messages.
Page 107 For example, if you want to print your company name and a time/date stamp, you would enter: Kodak %T %Y. This would print: Kodak 10:10 10232001 NOTES: This alpha character following the % sign is case sensitive.
Page 108 Sequential Counter %S: this value is used to assign the – document count for the next document entering the transport. This value is incremented sequentially by the scanner unless another document count is received from the host. This value is returned in the image header.
Page 109 This value is incremented sequentially by the scanner unless another document count is received from the host. This value is returned in the image header.
Page 110: Text Options
A-61510 January 2005 Text Options Top Margin: allows you to define the distance from the lead edge before the print string begins. This value can be defined in Inches, Centimeters or Pixels. Set this value using the slider bar. Start position Printing area NOTE: Printing automatically stops 6.3 mm (1/4-inch) from the trailing edge of the document even if the information has not been...
Page 111 A-61510 January 2005 Font/Orientation: You can select the orientation you want your information to be printed in as well as the location on your document. Character sizes: Normal or Large Font Orientation: Portrait or Landscape. Direction: Up or Down You can choose: Large Landscape Down Large Portrait Down Normal Landscape Down...
Page 112 Color Dropout dialog box is displayed: Side select the side you want to apply Color Dropout values to either Front or Back. Dropout Color the i800 Series Scanners can drop out red, green or blue. None is the default. 4-31...
Page 113 (pre-thresholded) image for the color being removed. Therefore, this value should be higher than the threshold value selected on the Scanner Settings dialog box for this pixel to become the background color. The default value is 160.
Page 114 Defining Batch and Patch Code Definition values Enabling Batch Separation A-61510 January 2005 Batching is the operation of counting pages or documents. The Batch function allows you to define the level to count the number of documents in the batch and any actions to be taken at the beginning and end of a batch.
Page 115 Patch Codes click the Enable Patch Codes box. Recognition Modes allows you to select the patch type the scanner will recognize. You can select Level 2, Level 3, Feature Patch, or Transfer Patch. Each of these patch types is described in detail below.
Page 116 Beep when Patch Code is Detected used to signal that a patch has been recognized. The default is no confirmation tone. See Kodak publication A-61599, Patch Code Information for Kodak Document Scanners, for complete information. these patch types can be (Do not use these patches for production –...
Page 117 Image addressing A-61510 January 2005 Image addressing provides better document management opportunities. Image addressing is used for document tracking, batch control and image management. The Image Address dialog box allows you set an image address starting point and increment the image address according to how the application is setup.
Page 118 Address%3L%2L%1L represents a fixed field value of address and a 3 level image address. The i800 Series Scanners have more options available for image addressing schemes with the following guidelines: You may define from 0 to 4 fixed fields. Fixed fields can be a maximum of 9 characters.
Page 119 Width: a value of 0 indicates that no image address level will be used. Widths cannot exceed 9 characters. Level to Follow: these are the rules the scanner follows to set the next image address level if there are no other inputs. For example, patch sheet or end of batch processing.
Page 120: Defining The Scan Area
A-61510 January 2005 The Scan Area dialog box is only available for images when the Cropping option selected on the Scanner Settings dialog box is either Fixed Cropping or Relative Cropping. NOTE: Select the side and image to be defined by highlighting Front...
Page 121 Height — the height of the scanning area. If Overscan is not selected, the scanner will not continue capturing beyond the trail edge of the document. For example, if you set up the scanner for portrait-fed 8 ½” x 11” documents, and you scan an 8 ½ x 4”...
Page 122: Appendix A High Volume Scanner Comparison Table
End of Batch Function Length Monitor Maximum Document Length Length Error Response Patch Definition Transfer Patch Definition Printer Fonts/Orientation A-61510 January 2005 The chart below provides a comparison of Kodak High Volume Scanners. 7520 Mode Host Mode 9520 Host Host...
Page 123 EASTMAN KODAK COMPANY Document Imaging Rochester, New York 14650 Kodak is a trademark of Eastman Kodak Company. A-61510 1/05 Eastman Kodak Company, 2005...
