  • Page 1 i800 Series Scanners User’s Guide A-61169 Part No. 9E3959 CAT No. 129 5237...

  • Page 2: User Precautions

    Remove all other loose objects from the area that could be drawn into the machine. Take sufficient breaks to maintain mental alertness. Follow the recommended Kodak cleaning procedures. Do not use air, liquid or gas spray cleaners. These cleaners only displace the dust, dirt or debris to another location within the scanner, which could cause the scanner to malfunction.
  • Page 3 Taiwan Japan Class A This equipment is in the Class A category (Information Technology Equipment to be used in commercial and/or industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference by Information Technology Equipment aimed at preventing radio interference in commercial and/or industrial areas.

  • Page 4: Table Of Contents

    Table of Contents Introduction ..............1-1 Product description ............1-2 Standard features ..............1-2 Standard configurations .............1-3 Transport speed..............1-3 Speeds and resolutions .............1-3 Scanner specifications ............1-4 Dimensions ..............1-4 Minimum clearances ............1-4 Acoustic noise..............1-4 Electrical ..............1-4 Power system connection ..........1-4 Environmental ..............1-4 External components ............1-5 Back of scanner ..............1-5 Environmental information and equipment disposal ..1-6 Using the Scanner ............2-1...
  • Page 5 Operator Control Panel Functions .........3-1 Enabling and disabling the scanner ........3-2 Enabling the scanner ...........3-2 Disabling the scanner ..........3-3 Navigating through the functions on the control panel menu ..............3-4 Accessing information............3-5 Lowering the elevator tray..........3-5 Using the Diagnostics Settings menu ........3-5 Performing a self-test or extended self-test ....3-6 Running in count-only mode ........3-6 Performing a print test..........3-7...
  • Page 6 Maintenance ..............5-1 Cleaning the paper path.............5-1 Cleaning the upper transport area ........5-2 Cleaning the vertical transport area ........5-5 Cleaning the transport area ..........5-6 Cleaning the printer and patch head........5-9 Cleaning the imaging guides..........5-10 Maintenance and replacement procedures......5-11 Replacing the feed module and feed module tires...5-12 Replacing the feed module ........5-13 Replacing the feed module tires ........5-13 Separation roller and tires..........5-15...

  • Page 7: Introduction

    Introduction This User’s Guide provides information and operator procedures for the Kodak i800 Series Scanners. The information in this guide is for use with all of the i800 Series Scanners unless otherwise noted. Chapter 1, Introduction provides general information about the i800 Series Scanners including a product description, features and benefits, specifications, an overview of external components and user precautions.

  • Page 8: Product Description

    The Kodak i800 Series Scanners are ideal for operation with bi-tonal Product description and/or color/grayscale documents, documents with shaded backgrounds or foregrounds, and mixed document sets. These scanners offer a new, user interface and Kodak-patented technologies that produce high quality production images.

  • Page 9: Standard Configurations

    Four models of the Kodak i800 Series Scanners are available: Standard configurations Kodak i810 Scanner (bi-tonal) provides bi-tonal scanning with throughput speeds up to 120 ppm Kodak i820 Scanner provides color/grayscale and bi-tonal scanning simultaneously with throughput speeds up to 120 ppm...

  • Page 10: Scanner Specifications

    Following are the dimensions and clearances for the Kodak i800 Series Scanner specifications Scanners: Dimensions Height: 124 cm (49 in.) Width: 66 cm (26 in.) Depth: 127 cm (50 in.) Weight: 204 kg (450 lbs) including packaging 188 kg (414 lbs) without packaging...

  • Page 11: External Components

    See the illustration below for the location of the external components of External components the scanner. Top cover Swing out door Bi-fold door Output tray panel Operator control Power switch Side guides Gap release lever Elevator tray Feed module Feeder extensions Back of scanner Power cord SCSI Connector...

  • Page 12: Environmental Information And Equipment Disposal

    The product packaging is recyclable. Parts are designed for reuse or recycling. The Kodak i800 Series Scanners contain lead in the circuit boards and mercury in the lamps. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or visit the Electronics Industry Alliance website: www.eiae.org.

  • Page 13: Using The Scanner

    Using the Scanner This chapter provides the following operational procedures: Turning on the scanner Document preparation Adjusting the input tray, side guides and output tray Scanning documents Feeding long documents Continuous and manual feeding Other functions, such as calibration, using the programmable keys, using multi-feed detection, setting the elevator level, etc.

  • Page 14: Document Preparation

    Kodak scanners have been tested with a range of documents that Document preparation represent the broad spectrum of document types found in the most common business applications. Optimal scanner performance is achieved when you scan documents within the recommended document specifications listed below.

  • Page 15: Acceptable Document Materials

    For heavily damaged documents, a clear document protector can be used with the following limitations: – Manual feeding is recommended when using a clear document protector. – The document in the clear document protector must be fed under both feed module tires. –...

  • Page 16: Maximum Document Batch Height For Automatic Feeding

    Maximum document When feeding batched documents, the maximum height of the batched batch height for documents is 10.2 cm (4 in.), approximately 1000 sheets of 75g (20 lb.) automatic feeding paper. The elevator tray can be set to accommodate 25-, 250- 500-, 750- 1000-document stacks.

  • Page 17: Adjusting The Output Tray

    Different paper types stack differently. The output tray can be set with Adjusting the output either the front or the rear higher for best stacking. tray To angle the output tray so the back of the output tray is higher: 1.

  • Page 18: Scanning Documents

    Before you scan documents, be sure the menu bar is displayed on the Scanning documents Operator Control Panel. Operator Control panel Documents must be fed under both feed module tires. For faster throughput, feed documents into the elevator tray in landscape orientation (longer side as the leading edge).

  • Page 19: Loading Long Documents In The Feeder

    The feeder accommodates documents up to 76.2 cm (30 in.) in length. To Loading long feed documents longer than 30.5 cm (12 inches): documents in the feeder Pull out the document extenders. Document extenders 2. Place the documents in the elevator tray. NOTE: Operator assistance is required when feeding documents longer than 43.2 cm (17 in.).

  • Page 20: Feeding Thick Documents

    To feed thick documents: Feeding thick documents 1. Press and hold the gap release lever this provides more clearance to ease document feeding. Gap release lever 2. Push the envelope/thick document into the transport. If more than one document is to be scanned, feed them into the transport one at a time. 3.

  • Page 21: Operator Control Panel Functions

    Operator Control Panel Functions There are a variety of functions available from the Operator Control Panel. This chapter provides procedures and information for: Enabling and disabling the scanner Control Panel functions overview Navigating through the functions on the Control Panel menu Accessing information Lowering the elevator tray Using the Diagnostics Settings menu...

  • Page 22: Enabling And Disabling The Scanner

    The five buttons at the bottom of the Control Panel correspond to the Enabling and disabling icons above the buttons To activate the icons, press the corresponding the scanner button. Icons Control panel buttons The scanner can only be enabled from the host computer. When the Enabling the scanner scanner is enabled, you can change the image address level, override the elevator setting and use the programmable keys.

  • Page 23: Disabling The Scanner

    The scanner can be disabled from the host computer or the scanner, if Disabling the scanner the end-of-job function is assigned to one of the programmable keys. When the scanner is disabled, you can display scanner information, lower the elevator tray, use the Diagnostics Settings menu, calibrate the scanner and jog the transport.

  • Page 24: Navigating Through The Functions On The Control Panel Menu

    The left and right arrows navigate along the top of the menu bar. Navigating through the functions on the control panel menu In this example, the left and/or right arrow will rotate through the options of Exit, Diagnostics and Settings. Exit Diagnostics Settings...

  • Page 25: Accessing Information

    The information icon will display information including the last image Accessing information address, meter values, and scanner serial number. Select this icon to display information. 0.0.0.1 Pages: 22453 Hours on: 447 Hours feeding: 32 S/N: 76858463 Lowering the elevator The level of the elevator tray can be set to accommodate various sizes of document batches.

  • Page 26: Performing A Self-Test Or Extended Self-Test

    You can perform a self-test or an extended self-test on the scanner. The Performing a self-test or self-test is the same test performed when the scanner is powered-up; the extended self-test extended self-test is a more thorough test. To perform a self-test or extended self-test: 1.

  • Page 27: Performing A Print Test

    The print test checks to be sure the ink jets in the Document Printer are Performing a print test functioning properly. To perform a print test: 1. Select the Diagnostics Settings menu icon. 2. Use the right or left arrow to navigate to the Diagnostics function. 3.

  • Page 28: Performing A Patch Test

    Use this test to verify that the Patch Reader is operational and that your Performing a patch test patches are within specification. To perform a patch test: 1. Select the Diagnostics Settings menu icon. 2. Use the right or left arrow to navigate to the Diagnostics function. 3.

  • Page 29: Using The Settings Menu

    Using the Settings The Menu icon displays the Diagnostics Settings menu. menu Exit Diagnostics Settings The following Settings functions are available: Changing the Alarm Volume Changing the Display Contrast Changing the SCSI ID Changing the SCSI Termination Setting the Elevator Position This setting allows you to adjust the volume of the alarm from 0 to 4.

  • Page 30: Changing The Display Contrast

    Changing the SCSI ID should not be changed unless directed to do so by your integrator or Kodak Field Representative. If the SCSI ID has been changed, you must reboot the scanner. After the scanner has been powered up and completed the self-test, reboot the host PC.

  • Page 31: Changing The Scsi Termination

    The SCSI termination should not be changed unless directed to do so by your integrator or Kodak Field Representative. To change the SCSI termination: 1. Select the Diagnostics Settings menu icon.

  • Page 32: Setting The Elevator Tray Position

    4. Select Return. SCSI termination : 0 5. Use the up and down arrows to select the desired SCSI termination setting. 6. Select Return. 7. Turn the scanner off. Wait at least 10 seconds and turn the scanner back on again. The new termination setting will take effect. This setting allows you to select a position of the elevator tray.

  • Page 33: Calibrating The Scanner

    4. Select Return. Elevator position : 1000 5. Use the down arrow to select the desired elevator position. 6. Select Return. The elevator position takes effect after the scanner is enabled. Calibration optimizes your scanner to achieve the best image quality and Calibrating the scanner feeding performance.

  • Page 34: Jogging The Transport

    The Jog button temporarily (4 seconds) turns on the transport to help Jogging the transport clear a document jam. This function is only available when the scanner is disabled. The Jog button is intended to clear simple document jams. If documents are lodged in several locations within the scanner, use the procedures in Chapter 6, Troubleshooting/Messages.

  • Page 35: Document Printer And Patch Reader

    Document Printer and Patch Reader This chapter provides instructions for using the Kodak Imagelink Document Printer 1 and the Patch Reader. The following can be found in this chapter: Purging the ink cartridge Replacing the ink cartridge Replacing the ink blotter strips...
  • Page 36 The Document Printer can print one line per document. The information printed by the Document Printer appears in a single column perpendicular to the leading edge of the document(s) as shown: Font size: two different character sizes, referred to as Large and Small, are available.

  • Page 37: Horizontal Print Position

    The horizontal print position is set using one of the 13 positions in the Horizontal print position Document Printer well. Print position can be manually changed as required. To change the print position: 1. Open the swing out door. 2. Slide the green ink cartridge carrier out of its slot. 3.

  • Page 38: Purging The Ink Cartridge

    Additional ink cartridges can be purchased from an office supply retailer Purging the ink cartridge nearest you. NOTES: If the Document Printer will not be used for a period of time (24 hours or more), remove the Document Printer from the carrier and place it on its side until you are ready to use it.

  • Page 39: Replacing The Ink Cartridge

    4. Gently press the paper clip against the side of the ink bladder until a small bead of ink appears on the ink flow point on the ink cartridge. CAUTION: Do not puncture the ink bladder with the paper clip. 5.
  • Page 40 3. Raise the locking bar if it is not already in the raised position and remove the empty ink cartridge. Locking bar 4. Insert a new, purged ink cartridge. 5. Lower the locking bar around the ink cartridge. 6. Slide the green ink cartridge carrier back into its slot. 7.

  • Page 41: Replacing The Ink Blotter Strips

    Ink blotter strips collect ink overflow. They should be replaced when there Replacing the ink blotter is a build-up of ink. Replacement blotter strips may be purchased through strips your supplier. See Chapter 5, Maintenance, for a list of available supplies.
  • Page 42 5. Grasp a blotter strip and carefully pull it off the transport. Discard the soiled strips. 6. Install the new blotter strip. Make sure that you align it in the transport channel before pressing the adhesive side into the channel. 7.

  • Page 43: Setting The Printer Position

    There are 13 possible positions for the printer. Make sure that the printer Setting the printer is in the correct position for your documents. position 1. Open the swing out door. 2. Locate the printer positioning slots. 3. Determine which position is suitable for your printing needs. 4.

  • Page 44: The Patch Reader

    There are 5 possible patch head positions. The patch head position can be easily changed. Recognition of all patch types will be returned in the image header. This is in addition to document level information. See Kodak publication A-61599, Patch Code Information, for complete information. Patch types...

  • Page 45: Patch Code Placement

    Patch Types 2, 3 and T these patch types are used for image addressing. When the Patch Reader detects a patch, it automatically assigns a new image address to the new document. This eliminates the task of trying to determine where one document stops and the next starts when you are viewing electronic images.

  • Page 46: Setting The Patch Reader Position

    There are 5 patch locations available for patch reading. Setting the Patch Reader position 1. Set the documents in the elevator tray. 2. Open the swing out door. 3. Align the patch head with the location of the patch on the documents. 4.

  • Page 47: Maintenance

    8-hour shift, unless otherwise noted. Additional maintenance supplies can be ordering by calling DI Supply or through your Kodak Reseller. For a list of available supplies, see the section entitled, “Ordering Supplies” at the end of this chapter.

  • Page 48: Cleaning The Upper Transport Area

    Follow the steps below to clean the upper transport area: Cleaning the upper transport area 1. Open the top cover. 2. Open the bi-fold door. 3. Grasp the end of the lower imaging guide and slowly pull it straight out. 4.
  • Page 49 5. Grasp the end of the upper imaging guide and slowly pull it straight out. 6. Place the upper imaging guide on a clean surface. NOTE: To avoid getting any debris (from the cleaning process) on the imaging guides, they will be reinstalled after the scanner is thoroughly cleaned.
  • Page 50 10. Lift and hold the exit transport plate and vacuum. 11. Lower the exit transport plate. A-61169 January 2005...

  • Page 51: Cleaning The Vertical Transport Area

    Follow the steps below to clean the vertical transport area: Cleaning the vertical transport area 1. Grasp the vertical transport plate and pull it down until it stops. 2. Slide the horizontal baffle plate out and vacuum inside the housing. Document sensors Black strip Horizontal baffle plate...

  • Page 52: Cleaning The Transport Area

    6. Vacuum the floor of the lower transport area. 7. Raise the vertical transport plate into its original position. 8. Turn the vertical transport plate handle and latch it into place. 9. Close the bi-fold door. 10. Close the top cover. Follow the steps below to clean the transport area: Cleaning the transport area...
  • Page 53 2. Lift the roller cover and vacuum the sensors. Roller cover Sensors IMPORTANT: When vacuuming the scanner, be careful not to scratch the sensors. 3. Close the roller cover. 4. Lift the horizontal transport plate. 5. Remove the horizontal belt module. A-61169 January 2005...
  • Page 54 6. Remove the dust pan and empty any debris. 7. Using the long-handled brush, clean the mirrors which are located deep inside the scanner. 8. Vacuum the floor of the horizontal transport area. 9. Reinsert the dust pan. 10. Wipe the upper and lower sensors with a lint-free cloth. 11.

  • Page 55: Cleaning The Printer And Patch Head

    Follow the steps below to clean the Document Printer 1 and Patch Cleaning the printer Reader head. Complete instructions for the Document Printer and Patch and patch head Reader can be found in Chapter 4. 1. Remove the Document Printer head and clean it with a dry, lint-free cloth.

  • Page 56: Cleaning The Imaging Guides

    Avoid getting fingerprints on the imaging guides during the cleaning Cleaning the imaging procedure. guides 1. Open the bi-fold door. 2. Get the upper imaging guide that was set aside previously. Clean the upper imaging guide with a clean, soft, lint-free cloth slightly moistened with water.

  • Page 57: Maintenance And Replacement Procedures

    This section provides procedures for replacing the following parts. Use Maintenance and the list below as a guideline for frequency of replacement. replacement procedures Feed Module Tires and Separation Roller – tire life will vary depending upon paper types, environment and cleanliness. Nominal tire life will be approximately 250,000 documents;...

  • Page 58: Replacing The Feed Module And Feed Module Tires

    This section provides replacement procedures for the feed module and Replacing the feed the feed module tires. module and feed module tires To replace the feed module: Replacing the feed module 1. Open the swing out door. 2. Push the release lever to the right to release the feed module. 3.

  • Page 59: Replacing The Feed Module Tires

    To replace the feed module tires: Replacing the feed module tires 1. Open the swing out door. 2. Remove the feed module. 3. With one hand, press the locking tabs (one on each side) while holding the bottom housing with the other hand, pull the upper housing up and away from the rollers.
  • Page 60 6. Install each new tire by gently stretching it over the core. IMPORTANT: Do not overstretch the tire; it may tear. 7. Replace the core assembly in the feed module. 8. Repeat Steps 4 through 7 for the other core assembly. 9.

  • Page 61: Separation Roller And Tires

    This section provides procedures for changing the separation roller and Separation roller and tires. tires Replacing the separation To replace the separation roller: roller 1. Open the swing out door. 2. Lift the roller cover. 3. Pull the separation pad holder forward and remove the separation roller.

  • Page 62: Replacing The Separation Roller Tires

    To replace the separation roller tires: Replacing the separation roller tires 1. Remove the separation roller as previously directed. 2. Replace each tire by sliding the tire off the core. 3. Install each new tire by gently stretching it over the core. IMPORTANT: Do not overstretch the tire;...

  • Page 63: Roller Tires

    The cleaning procedures below should be performed daily. More frequent Cleaning the feed module cleaning may be necessary depending on throughput and document type. tires and separation Daily cleaning of the feed module tires and separation roller tires prevent roller tires ink, toner, dust and paper contaminates from collecting on the rollers, which help documents to separate properly when feeding.
  • Page 64 2. Grasp the green handle of the lamp connector. 3. Slightly raise the edge of the black holder and remove the lamp connector. 4. Grasp the end of the lamp and slowly pull the lamp straight out. NOTE: Like most fluorescent lamps, these lamps contain a small amount of mercury and should be disposed of in accordance with local regulations.
  • Page 65 5. Position the new lamp in the lamp holder. IMPORTANT: Make sure that the clear surface of the lamp is positioned facing the imaging guides. (NOTE: The imaging guides are not installed in the illustration above.) Replace one lamp at a time to ensure the correct connector is inserted with each lamp;...

  • Page 66: Replacing The Imaging Guides

    To replace the imaging guides: Replacing the imaging guides 1. Open the bi-fold door. 2. Remove the imaging guides. 3. Slide a new upper imaging guide in place. Make sure the notched side is facing down and that the imaging guide is pushed in all the way and fully seated in its slot.

  • Page 67: Customizing The Side Guides For Self-Centering Feeding

    A spacer is installed in the output tray, which allows the side guides to Customizing the side move independently. If you want the side guides to move together (self- guides for self- centering) you can install the geared spacer that is included with the centering feeding scanner.
  • Page 68 3. Use the screwdriver to release the center screw. 4. Remove the spacer and washer. 5. Take the geared spacer and place it over the post, being sure to align the teeth on the racks. 6. Add the washer and screw and gently tighten until the spacer and washer are firm.

  • Page 69: Changing The Output Tray Side Guides

    7. Turn the tray right-side up, reinstall the end stop and verify the guides move freely. 8. Replace the output tray. Changing the output The output tray comes with a set of short and tall side guides, which can be easily changed. tray side guides Tools needed: Phillips Head Screwdriver 1.
  • Page 70 6. Take one tall (or short) side guide, position the guide and hold it in place. 7. Continue to hold the side guide in place and turn the output tray over. Put the screws in place and tighten. 8. When finished with the first side guide, turn the tray back over and attach the other side guide;...

  • Page 71: Ordering Supplies

    The following supplies are available to properly maintain your system. Ordering supplies Order them in the United States by calling DI Supply at 1-888-247-1234 or contact your local Kodak Reseller. Outside of the United States, contact your local Kodak dealer. Description CAT No. Calibration Target (Qty 50)

  • Page 72: Troubleshooting/Messages

    Troubleshooting/Messages This chapter provides the following: procedures for clearing the document path, information regarding document printing problems, a message listing and the actions you can take to clear the message, a problem solving chart and when to call Service. In the rare instance when a document becomes lodged in the transport, Clearing the document the scanner stops running and a message appears on the Operator path...
  • Page 73 If there are still lodged documents: 3. Open the swing out door. 4. Lift the horizontal transport plate and remove any documents. 5. Close the horizontal transport plate. 6. Close the swing out door. Top cover access 7. Open the top cover. 8.
  • Page 74 10. Open the upper turn roller and remove any lodged documents. 11. Close the upper turn roller. 12. Close the top cover. Clearing the document path – bi-fold door access Occasionally documents can become lodged in the imaging guide area. If this is the case: 13.
  • Page 75 16. Slide out the horizontal baffle plate and remove any lodged documents. 17. Slide the horizontal baffle plate back into position and close the vertical transport plate. NOTE: Be sure the vertical transport plate is securely locked into position. 18. Reinstall the imaging guides. 19.

  • Page 76: Message Listing

    Following is a list of messages and corrective actions you can take if one Message Listing of the following messages appears on the Operator Control Panel. Most corrective actions can be found in this User’s Guide; appropriate chapters are referenced. If one of the following messages appears, take the following action: Determine whether or not the error can be addressed from the host system.
  • Page 77 Message Description Message Check document preparation The documents are not prepared properly for scanning. See Chapter 2, Using the Action Scanner, for procedures on how to properly prepare your documents. The documents are too close together as they enter the scanner. Change the separation rollers and pre-separation pad.
  • Page 78 Invalid IA level Action The image address level you tried to enter is not valid. Re-enter a correct image address level. For more information about image addressing, see Kodak publication, Kodak i800 Series Scanners, Image Processing Guide, A-61510. Message IPB needs firmware There is no firmware in an image processing board.
  • Page 79 Message Description Message Mechanical cal unsuccessful The mechanical calibration was unsuccessful. Be sure the correct calibration Action target was used and that the arrows on the target were feed into the transport first. See Chapter 3, Operator Control Panel Functions, “Calibration” for more information.
  • Page 80 Conflicting or unacceptable settings have been downloaded to the scanner. For Action example, if you attempt to set a 200 dpi bi-tonal front with a 300 dpi bi-tonal rear or if you try to enable color scanning on a Kodak i810 or i830 Scanner. A-61169 January 2005...

  • Page 81: Document Sensor Location

    Message Description Message Unable to enable Check to be sure all doors are closed. If all the doors are closed, perform a Action controlled power-down sequence. If the error persists, call Service. Message Unable to execute command Action You have tried to perform a function that is not permitted in the current state of the scanner or with invalid parameters.

  • Page 82: Problem Solving Chart

    Use the chart below as a guide to check possible solutions to problems Problem solving chart you may encounter when using the Kodak i800 Series Scanners. Problem Possible Solutions Scanner does not power on Make sure that: (Control Panel is not...
  • Page 83 Problem Possible Solutions Calibration has failed Make sure that: the lamps have been on at least 10 minutes. you are using the proper calibration target and it is oriented correctly. the imaging guides are clean (see Chapter 5, Maintenance, “Cleaning the imaging guides”).
  • Page 84 Problem Possible Solutions The output tray cannot be Make sure the output tray is installed properly. adjusted in or out Roller marks appear on Clean the feed module rollers, separation rollers and transport rollers (see documents after scanning Chapter 5, Maintenance). Be sure when you calibrate the scanner that you are using a good, clean Vertical streaks appear on calibration target.
  • Page 85 Problem Possible Solutions White lines appear at the Clean the black backer strip on the horizontal baffle plate. For procedures see top of the document then Chapter 5, “Cleaning the vertical transport area”. stop as the document is imaged. 6-14 A-61169 January 2005...
  • Page 86 EASTMAN KODAK COMPANY Commercial Imaging Rochester, New York 14650 Kodak is a trademark of Eastman Kodak Company. Printed on recycled paper. A-61169 1/05 CAT No. 129 5237 © Eastman Kodak Company, 2005 Printed in U.S.A.
