Cleaning the printer
and patch head
A-61169 January 2005
Follow the steps below to clean the Document Printer 1 and Patch
Reader head. Complete instructions for the Document Printer and Patch
Reader can be found in Chapter 4.
1. Remove the Document Printer head and clean it with a dry, lint-free
cloth.
2. Reinstall the Document Printer head in the desired position.
IMPORTANT: Be sure the cable is always kept in place by the white clip
to prevent the cable from interfering with the imaging path.
3. Remove the patch head and clean it with a dry, lint-free cloth.
4. Replace the patch head in the desired position.
5. Close the swing out door.
White clip
5-9
