I
M
nstruction
anual
for Kodak Scanners
Cleaning and Consumable Replacement Instructions
i800/i810/
i820/i830/i840
Versitec is a division of Cranel, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the i800 and is the answer not in the manual?

Questions and answers

Related Manuals for Kodak i800

Summary of Contents for Kodak i800

  • Page 1 Kodak Scanners Cleaning and Consumable Replacement Instructions i800/i810/ i820/i830/i840 Versitec is a division of Cranel, Inc.
  • Page 2 INSTRUCTION MANUAL FOR KODAK i800/i810/i820/i830/i840 Scanner Versitec 1- 888 - 722 - 6548 www. versitec.com...
  • Page 4 Step Four: Cleaning the Transport area....8 - 10 Step Five: Cleaning the Printer and Patchhead..10 - 11 Step Six: Cleaning the Imaging Guides ....12 - 13 II. i800 Maintenance and Replacing Procedures Step One: Replacing the feed Module & feed Module Tires..........14 Step Two: Replacing the feed Module ....14 - 15...
  • Page 5 8-hour shift, unless otherwise noted. Additional maintenance supplies can be ordering by calling DI Supply or through your Kodak Reseller. For a list of available supplies, see the section entitled, “Ordering Supplies” at the end of this chapter.
  • Page 6 Feed the cleaning sheet (adhesive side up) in the landscape orientation several times through the transport. Feed the cleaning sheet (adhesive side down) in the landscape orientation several times through the transport. NOTE: When a cleaning sheet gets dirty, discard it and use a new one. Cleaning the upper transport area Follow the steps below to clean the upper transport area: Open the top cover.
  • Page 7 Open the bi-fold door. Grasp the end of the lower imaging guide and slowly pull it straight out. Place the lower imaging guide on a clean surface. Grasp the end of the upper imaging guide and slowly pull it straight out. Versitec 1- 888 - 722 - 6548 www.
  • Page 8 Place the upper imaging guide on a clean surface. NOTE: To avoid getting any debris (from the cleaning process) on the imaging guides, they will be reinstalled after the scanner is thoroughly cleaned. Release the top turn baffle. Top turn baffle Exit transport...
  • Page 9 Lift and hold the exit transport plate and vacuum. Lower the exit transport plate. Cleaning the vertical transport area Follow the steps below to clean the vertical transport area: Grasp the vertical transport plate and pull it down until it stops. Versitec 1- 888 - 722 - 6548 www.
  • Page 10 Slide the horizontal baffle plate out and vacuum inside the housing. Document sensors Black strip Horizontal baffle plate With a soft cloth, wipe the document sensors and the black strip on the horizontal baffle plate. IMPORTANT When vacuuming the scanner, be careful not to scratch thesensors.
  • Page 11 Raise the vertical transport plate into its original position. Turn the vertical transport plate handle and latch it into place. Close the bi-fold door. Close the top cover. Cleaning the transport area Follow the steps below to clean the transport area: Open the swing out door.
  • Page 12 Lift the roller cover and vacuum the sensors. Roller cover Sensors IMPORTANT When vacuuming the scanner, be careful not to scratch the sensors Close the roller cover. Lift the horizontal transport plate. Versitec 1- 888 - 722 - 6548 www. versitec.com...
  • Page 13 Remove the horizontal belt module. Vacuum the floor of the horizontal transport area. Wipe the upper and lower sensors with a lint-free cloth. Reinstall the horizontal belt module. Lower the horizontal transport plate. Cleaning the printer and patch head Follow the steps below to clean the Document Printer 1 and Patch Reader head.
  • Page 14 Remove the Document Printer head and clean it with a dry, lint-free cloth. White clip Reinstall the Document Printer head in the desired position. IMPORTANT Be sure the cable is always kept in place by the white clip to prevent the cable from interfering with the imaging path. Remove the patch head and clean it with a dry, lint-free cloth Replace the patch head in the desired position.
  • Page 15 Cleaning the imaging guides Avoid getting fingerprints on the imaging guides during the cleaning procedure. Open the bi-fold door. Get the upper imaging guide that was set aside previously. Clean the upper imaging guide with a clean, soft, lint-free cloth slightly moistened with water. Lightly wipe both sides with a Staticide wipe.
  • Page 16 Close the bi-fold door. i800 Maintenance & i800 Maintenance & II. i800 Maintenance & i800 Maintenance & i800 Maintenance & replacement procedures replacement procedures...
  • Page 17 This section also provides replacement procedures for the: • Gear for Self-Centering Side Guides – a spacer is installed in the output tray, which allows the side guides to move independently. If you want the side guides to move together (self-centering) you can install the geared spacer that is included with the scanner.
  • Page 18 Remove the feed module. To install the new feed module: Push the release lever to the right and reinsert the new feed module by aligning the pins and fitting it into position. When the feed module is in position, release the lever and be sure the feed module is securely in place.
  • Page 19 6. Install each new tire by gently stretching it over the core. Remove one core assembly. Replace each tire by sliding the tire off the core. Tire Core Install each new tire by gently stretching it over the core. Versitec 1- 888 - 722 - 6548 www.
  • Page 20 IMPORTANT Do not overstretch the tire; it may tear. Replace the core assembly in the feed module. Repeat Steps 4 through 7 for the other core assembly. Align the tabs on the upper housing with the slots on the lower housing. Press the upper and lower housings together until they snap into place.
  • Page 21 Separation roller and tires This section provides procedures for changing the separation roller and tires. Replacing the separation rollers To replace the separation roller: Open the swing out door. Lift the roller cover. Pull the separation pad holder forward and remove the separation roller.
  • Page 22 NOTE: Be sure to line up the slots on the separation roller with the holders. Push the separation roller holder back in place. Lower the roller cover. Close the swing out door. Replacing the separation roller tires To replace the separation roller tires: Remove the separation roller as previously directed.
  • Page 23 Install the new pre-separation pad. Be sure it snaps into place. Lower the roller cover. Close the swing out door. Cleaning the feed module tires and separation roller tires The cleaning procedures below should be performed daily. More frequent cleaning may be necessary depending on throughput and document type.
  • Page 24 Rotate the feed module tires and separation roller tires and scrub with an Emulsiclean wipe. Continue cleaning until all residue is removed from the tires. Dry the tires with a dry, lint-free cloth. Reinstall the separation roller. Lower the roller cover. Reinstall the feed module.
  • Page 25 www.versitec.com Corporate Headquarters 8999 Gemini Parkway Columbus, OH 43240 Fax: 614.431.8388 Repair Center Western Region Office 908 Boston Turnpike Road 8001 Irvine Center Drive, 4th Floor Shrewsbury, MA 01545 Suites 411, 412, 413 Fax: 508.460.1890 Irvine, CA 92618 For inquiries on consumables, call Versitec at: 888.722.6548...
