- Page 1 Scanners Patch Code Information A-61599 CAT No. 845 9380 A-61599 October 2006...
- Page 2 Patch description This document provides information that supports the following scanners. • Kodak Scanners 9XYZ, 5XYZ, 7XYZ, i800/i1800 (with image addressing) Series Scanners and the Kodak Microimager 70—these scanners are equipped with the Patch Reader. The Patch Reader recognizes patches with bars that are parallel to the lead edge of the document. All of these scanners may use patches for image addressing.
- Page 3 Patch Types 1, 4 and 6 can be used by the host for post-scan image control for the i800/i1800 (with image addressing) Series Scanners (they are not used for image addressing). The Toggle Patch may be used to switch back and forth from bi-tonal and color/grayscale scanning for the i280, 3590C, i600, i800 and i1800 (without image addressing) Series Scanners.
- Page 4 For Kodak Scanners 9XYZ, 5XYZ, 7XYZ, i800/i1800 (with image addressing) Series Scanners and 70 Microimager: The minimum overall length of the patch bars is 2 inches (50 mm). Patch positioning Horizontal placement/positioning • There are five patch sensor locations for the...
- Page 5 Leading Edge of Document (fed into transport first) Vertical placement/positioning • Patch codes must appear at least 0.25 inches (6 mm) from the right, left, and leading edges of the document. 3.75 inches (94 mm) • Patch codes must appear no more than 3.75 inches (94 mm) from the leading edge of the document [1.6 inches (40 mm) on the 5XYZ and 7XYZ Scanners].
- Page 6 For i280, 3590C and i600/i1800 (without image addressing) Series Scanners • The Patch Reading Area ends 2.0 inches from the lead edge of the document. At least 0.75 inches of The minimum overall length of the patch bars is the patch code must appear within the Patch 0.75 inches (19 mm).
- Page 8 A-61599 10/06 Printed in U.S.A. Eastman Kodak Company Document Imaging Rochester, New York 14650 © Kodak,2006. Kodak is a trademark Kodak.
