Changing the SCSI
termination
A-61169 January 2005
3. Use the down arrow to select Change SCSI ID.
Exit Diagnostics
Change Alarm Volume
Change Display Contrast
Change SCSI ID
Change SCSI Termination
4. Select Return.
SCSI id : 2
5. Use the up and down arrows to select the desired SCSI ID number.
6. Select Return.
7. Turn the scanner off. Wait at least 10 seconds and turn the scanner
back on again.
8. After the scanner has completed the self-test, reboot the host PC.
This setting allows you to change the SCSI termination. Values are 0
(disabled) or 1 (enabled). By default, the SCSI termination is enabled and
remains enabled until you disable it and reboot the scanner. The SCSI
termination should not be changed unless directed to do so by your
integrator or Kodak Field Representative.
To change the SCSI termination:
1. Select the Diagnostics Settings menu
2. Use the right or left arrow to navigate to the Settings function.
3. Use the down arrow to select Change SCSI Termination.
Exit Diagnostics
Change Alarm Volume
Change Display Contrast
Change SCSI ID
Change SCSI Termination
Settings
icon.
Settings
3-11
