1 Server Chassis Features

This chapter briefly describes the main features of the Intel
list of the server chassis features and diagrams showing the location of important components and
connections on the server chassis.
Table 1 summarizes the features of the Intel
Feature
Dimensions
Hard Drives
Peripherals
Control Panel
(dependent on option
Server
Intel® Chassis SC5600 Service Guide

Figure 1. Intel

®
Server Chassis SC5600Base SKU.
®
Table 1. Intel Server Chassis SC5600Base Features
17 inches high (Rack: 16.6 inches)
8.6 inches wide
28.4 inches deep (Rack: 27.4 inches)
34.6 kilograms
Supports up to six drives, depending on peripheral choices
One fixed drive bay for up to six fixed SAS or SATA drives
Optional hot-swap drive bays:
•
Six-drive SAS/SATA (AXX6DRV3GR or AXX6DRV3GEXP)
Three multi-mount 5.25-inch peripheral bays
Front Control Panel
®
Server Chassis SC5600. This chapter provides a
®
Server Chassis SC5600
Description
Server Chassis Features
