Peripheral Devices
The chassis provides locations and hardware for installing hard drives, CD-ROM drive, DVD-ROM drive, or a
tape drive. You must purchase the drives separately. The following figure shows the available options.
Server
Intel®
Chassis SC5600 Service Guide
Callout
A.
DVD-ROM drive/CD-ROM drive (Optional)
B.
Front USB ports (2)
C.
4-Bay hot-swap hard disk drive bay (optional)
D.
6-Bay hot-swap hard disk drive bay (optional)
Figure 7. Optional Peripherals
Function
Server Chassis Features
11
