The power supply cord(s) is/are the main disconnect device to AC power. The socket outlet(s) must
be near the equipment and readily accessible for disconnection.
The power supply cord(s) must be plugged into socket-outlet(s) that is /are provided with a suitable
earth ground.

System Access Warnings

Caution: To avoid personal injury or property damage, the following safety instructions apply whenever accessing
the inside of the product:
•
Turn off all peripheral devices connected to this product.
•
Turn off the system by pressing the power button to off.
•
Disconnect the AC power by unplugging all AC power cords from the system or wall outlet. Disconnect all
cables and telecommunication lines that are connected to the system.
•
Retain all screws or other fasteners when removing access cover(s). Upon completion of accessing inside
the product, refasten access cover with original screws or fasteners.
•
Do not access the inside of the power supply. There are no serviceable parts in the power supply. Return to
manufacturer for servicing.
•
Power down the server and disconnect all power cords before adding or replacing any non hot-plug
component.
•
When replacing a hot-plug power supply, unplug the power cord to the power supply being replaced before
removing the power supply from the server.
Caution: If the server has been running, any installed processor(s) and heat sink(s) may be hot. Unless you are
adding or removing a hot-plug component, allow the system to cool before opening the covers. To avoid the
possibility of coming into contact with hot component(s) during a hot-plug installation, be careful when removing or
installing the hot-plug component(s).
Caution: To avoid injury do not contact moving fan blades. If your system is supplied with a guard over the fan, do
not operate the system without the fan guard in place.

Rack Mount Warnings

The equipment rack must be anchored to an unmovable support to prevent it from tipping when a server or piece of
equipment is extended from it. The equipment rack must be installed according to the rack manufacturer's
instructions.
Install equipment in the rack from the bottom up, with the heaviest equipment at the bottom of the rack.
Extend only one piece of equipment from the rack at a time.
You are responsible for installing a main power disconnect for the entire rack unit. This main disconnect must be
readily accessible, and it must be labeled as controlling power to the entire unit, not just to the server(s).
To avoid risk of potential electric shock, you must implement a proper safety ground for the rack and each piece of
equipment installed in it.

Electrostatic Discharge (ESD)

Caution: ESD can damage disk drives, boards, and other parts. We recommend that you perform all procedures at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist strap attached
to chassis ground -- any unpainted metal surface -- on your server when handling parts.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges. After
removing a board from its protective wrapper or from the server, place the board component side up on a grounded,
static free surface. Use a conductive foam pad if available but not the board wrapper. Do not slide board over any
surface.
