Preface

About this Manual

Thank you for purchasing and using the Intel
This manual is written for system technicians responsible for troubleshooting, upgrading, and repairing this
server chassis. This document provides a brief overview of the features of the board/chassis, list of
accessories or other components you may need, troubleshooting information, and instructions on how to add
and replace components on the Intel
http://support.intel.com/support/motherboards/server/chassis/SC5600/

Manual Organization

Chapter 1 provides a brief overview of the Intel
the server chassis features, photos of the product, and product diagrams to help you identify components and
their locations.
Chapter 2 provides instructions on adding and replacing components. Use this chapter for step-by-step
instructions and diagrams for installing or replacing components such as the memory, processor, front panel
board, and battery, among other components.
Chapter 3 provides technical reference information on cable routing, power supply specifications, and system
environment requirements.
At the back of this document, you will find appendices on safety, regulatory, "Getting Help", and warranty
information.
Product Accessories, Order Options, and Accessories
®
The Intel Server Chassis SC5600 family provides three SKUS: SC5600Base, SC5600BRP, and SC5600LX.
When a feature varies from each SKU, the difference is noted in this document. Unless specified, features
apply to all the three chassis SKUs.
®
The Intel Server Chassis SC5600Base is compatible with the following Intel
Boards:
Intel
Intel
Intel
Intel
®
The Intel Server Chassis SC5600BRP and SC5600LX are compatible with the following Intel
Intel
Intel
Intel
Server
Intel® Chassis SC5600 Service Guide
®
Server Chassis SC5600. For the latest version of this manual, refer to:
®
Server Board S5520HC
®
Server Board S5520HCT
®
Server Board S5500HCV
®
Workstation Board S5520SC
®
Server Board S5520HC
®
Server Board S5520HCT
®
Server Board S5500HCV
®
Server Chassis SC5600.
®
Server Chassis SC5600. In this chapter, you will find a list of
®
Server Boards and workstation
®
Server Boards:
Preface
v
