Attaching the unit tower to the wall (back
rails)
Drill through the rail into the wall to create a
pilot holes. Place wall plugs into the wall and
insert screw into the hole and tighten.
The installation manual should be checked to determine the fridge's position within the tower
unit.
Placing the shelves into position
The two shelves' positions will be determined
by aligning both the fridge doors and the
unit frontals, which may result in the fridge
needing to be raised.
To elevate the fridge (if required), the bottom
shelf must be lifted and packers placed
underneath to support the fridge. A filler can
be place at the front to hide the packers.
The top shelf will be placed at the top of the
fridge, as most fridges are screwed into the
shelf.
Use 4x L-brackets to secure the top shelf to
the unit.
If the top shelf is obstructed by the hinges,
it will need to be notched with a jigsaw to
accommodate the hinge.
