Wren Kitchens TOWER UNIT Assembly Manual

Diag corner larder with wine rack cabinet

Advertisement

Quick Links

TOWER UNIT
84", 90" & 96"
Diag Corner Larder
with Wine Rack Cabinet
Assembly
Guide
96" x 24"
90" x 24"
84" x 24"
70/30 Door
2 Door
For Internal Use: CON.INS.004.001_50-WKIN00007_TOWER45WineRack_Assembly_Rev3.indd

Advertisement

loading
Need help?

Need help?

Do you have a question about the TOWER UNIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wren Kitchens TOWER UNIT

  • Page 1 TOWER UNIT 84”, 90” & 96” Diag Corner Larder with Wine Rack Cabinet Assembly Guide 96” x 24” 90” x 24” 84” x 24” 70/30 Door 2 Door For Internal Use: CON.INS.004.001_50-WKIN00007_TOWER45WineRack_Assembly_Rev3.indd...
  • Page 2 TOWER UNIT BEFORE YOU START 84”, 90” & 96” INSTALLATION Diag Corner Larder SHOULD BE with Wine Rack Cabinet PERFORMED BY A COMPETENT PERSON ONLY. Assembly Guide THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel (Z) Carcase RH Carcase LH...
  • Page 3 TOWER UNIT Step 1. Lay both carcases LH & RH flat as shown. 84”, 90” & 96” Secure 5 x fixing plate (Ff) positioned onto outside Diag Corner Larder face of panel (Y) of carcase RH equally spaced using 2 x ”...
  • Page 4 TOWER UNIT 84”, 90” & 96” Diag Corner Larder Step 3. with Wine Rack Cabinet Secure leg base into place with ” screws (B) per leg as shown. Assembly Guide Ensure legs are rotated to also provide support to the end panels (Y).
  • Page 5 TOWER UNIT Step 6. Position carcase LH and carcase RH together as shown. 84”, 90” & 96” Diag Corner Larder Ensure carcases are flush & square. with Wine Rack Cabinet Assembly Guide Step 7. Screw through fixing plate (Ff) into adjoining carcase LH using ”...
  • Page 6 TOWER UNIT Step 9. 84”, 90” & 96” Use 2 x ” screws (B) to secure each of the Diag Corner Larder 4 x L brackets LGE (K) to both carcases positioned as shown. with Wine Rack Cabinet Assembly Guide...
  • Page 7 TOWER UNIT Step 11. When combined cabinet is secured in position, attach top Panel (Z), 84”, 90” & 96” Diag Corner Larder using 4x fixing plates (Ff) combined with 4 x ” screws (B) per plate, with Wine Rack Cabinet positioned as shown.
  • Page 8 TOWER UNIT Step 14. Attach hinge plates onto end panels (Y) to suit as 84” shown using 2 x ” screws (B) included per plate. Diag Corner Larder with Wine Rack Cabinet Hinge side to be mounted in accordance to customer kitchen plan.
  • Page 9 TOWER UNIT Step 14. Attach hinge plates onto end panels (Y) to suit as 90” shown using 2 x ” screws (B) included per plate. Diag Corner Larder with Wine Rack Cabinet Hinge side to be mounted in accordance to customer kitchen plan.
  • Page 10 TOWER UNIT Step 14. Attach hinge plates onto end panels (Y) to suit as 96” shown using 2 x ” screws (B) included per plate. Diag Corner Larder with Wine Rack Cabinet Hinge side to be mounted in accordance to customer kitchen plan.
  • Page 11 TOWER UNIT See Customer Specific Kitchen Plan For Tower Frontals 84”, 90” & 96” Diag Corner Larder with Wine Rack Cabinet Step 15. Insert hinge where required Assembly Guide in holes as shown. Step 16. Align doors & frontal toe kick to join together using Step 17.
