- Page 1 FRONTALS INFINITY PLUS INFINITY PLUS Attachment Guide Standard Drawer Deep Drawer Glass Side For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev1...
- Page 2 FRONTALS STANDARD DRAWER INFINITY PLUS STANDARD DRAWER Attachment Guide 4 1/2“ 4 1/2“ Standard Step 1. Drawer Attach the frontal fixings to the draw front 2 7/8“ 2 7/8“ 2 13/16“ 2 13/16“ using 3 x screws (B) per bracket using 5/8”...
- Page 3 FRONTALS DEEP DRAWER INFINITY PLUS Attachment Guide Frontal Fixings Step 1. Attach the frontal fixings to the draw front using 3 x 5/8” screws (B) per bottom bracket and 2 x screws (B) per top 5/8” bracket using the spiked positions. 7 15/16“...
- Page 4 FRONTALS DEEP DRAWER INFINITY PLUS Attachment Guide Frontal Fixings Step 1. Attach the frontal fixings to the draw front using 3 x 5/8” screws (B) per bottom bracket and 2 x screws (B) per top 5/8” bracket using the spiked positions. 7 15/16“...
- Page 5 FRONTALS GLASS REPLACEMENT INFINITY PLUS Attachment Guide GLASS OUT Step 1. Fully press the rear fixing clip in. Step 2. Insert the glass into the rear slot of the side panel and rotate the glass parallel to the side of the drawer. Step 3.
- Page 6 FRONTALS INFINITY PLUS Attachment Guide Page 5 For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev1...
- Page 7 FRONTALS INFINITY PLUS Attachment Guide For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev1 Page 6...
