ERROR SHOWED ON
SCREEN
[MOTOR PCB 4 ERROR]
[BLADE ROTATION
ERROR]
[BLADE 1 MOVEMENT
ERROR]
[BLADE 1 ROTATION
ERROR]
[BLADE 2 MOVEMENT
ERROR]
[BLADE 2 ROTATION
ERROR]
[BLADE 3 MOVEMENT
ERROR]
[BLADE 3 ROTATION
ERROR]
[BLADE 4 MOVEMENT
ERROR]
[BLADE 4 ROTATION
ERROR]
[MOTOR PCB 5 ERROR]
[FOCUS ERROR]
[4F PRISM ERROR]
[4F PRISM ROTATION
ERROR]
[FROST ERROR]
[ZOOM ERROR]
[PRISM ERROR]
[PRISM ROTATION
ERROR]
[FROST ERROR]
[IRIS ERROR]
POSSIBLE CAUSES
Motor pcb 5U not detected
Failure detected during the reset of the BLADE ROTATION,
if the focus lens is not located in its default position.
Failure detected during the reset of the BLADE 1 MOVE-
MENT, if the focus lens is not located in its default position.
Failure detected during the reset of the BLADE 1 ROTA-
TION, if the focus lens is not located in its default position.
Failure detected during the reset of the BLADE 2
MOVEMENT, if the focus lens is not located in its default
position.
Failure detected during the reset of the BLADE 2
ROTATION, if the focus lens is not located in its default
position.
Failure detected during the reset of the BLADE 3
MOVEMENT, if the focus lens is not located in its default
position.
Failure detected during the reset of the BLADE31
ROTATION, if the focus lens is not located in its default
position.
Failure detected during the reset of the BLADE 4
MOVEMENT, if the focus lens is not located in its default
position.
Failure detected during the reset of the BLADE 4
ROTATION, if the focus lens is not located in its default
position.
Motor pcb 6U not detected
Failure detected during the reset of the FOCUS, if the focus
lens is not located in its default position.
Failure detected during the reset of the 4F effect prism, if
this effect is not located in the default position.
Failure detected during the reset of the 4F effect prism
rotation, if this effect is not located in the default position.
Failure detected during the reset of the effect FROST, if this
effect is not located in the default position.
Failure detected during the reset of the ZOOM system, if
the focus lens is not located in its default position.
Failure detected during the reset of the PRISM, if the focus
lens is not located in its default position.
Failure detected during the reset of the PRISM ROTATION,
if the focus lens is not located in its default position.
Failure detected during the reset of the FROST, if the focus
lens is not located in its default position.
Failure detected during the reset of the IRIS, if the focus
lens is not located in its default position.
PROLIGHTS - Astra Profile900HQ
POSSIBLE PCB
WITH ANOMALY
6U
6U
6U
6U
6U
6U
6U
6U
6U
6U
7U
7U
7U
7U
7U
7U
7U
7U
7U
7U
