13 - DMX CHARTS
RDM Personality ID List
ID DMX Mode
1 STANDARD
Pan = 128
Tilt = 0
DMX
255
Pan = 0
Tilt = 42
DMX
255
Display
24
Footprint
20
PAN/TILT POSITION RELATED TO DMX VALUES
Home position set to STANDARD
Pan = 128
Tilt = 128
DMX
255
Tilt movement range: 270°
Pan movement range: 540°
Pan = 128
DMX
255
PROLIGHTS - Astra Profile900HQ
RDM Model ID
0xA027
DMX
0
Tilt = 42
DMX
0
Display
Pan = 128
Tilt = 255
DMX
0
Pan = 255
Tilt = 42
DMX
0
Display
Fig. 09
