12 - RDM FUNCTIONS
The product can communicate using RDM (Remote Device Management) protocol over a DMX512
Networks.
RDM is a bi-directional communications protocol for use in DMX512 control systems, it is the open
standard for DMX512 device configuration and status monitoring.
The RDM protocol allows data packets to be inserted into a DMX512 data stream without affecting
existing non-RDM equipment. It allows a console or dedicated RDM controller to send commands to
and receive messages from specific fixtures.
The PIDs in the following tables are supported in the product.
Category
DEVICE_INFO
PRODUCT_DETAIL_ID_LIST
DEVICE_MODEL_DESCRIPTION
MANUFACTURER_LABEL
Product
DEVICE_LABEL
Information
FACTORY_DEFAULTS
SOFTWARE_VERSION_LABEL
BOOT_SOFTWARE_VERSION_ID
BOOT_SOFTWARE_VERSION_LABEL
DMX_PERSONALITY
DMX_PERSONALITY_DESCRIPTION
DMX_START_ADDRESS
SLOT_INFO
DMX512 Setup SLOT_DESCRIPTION
DEFAULT_SLOT_VALUE
DMX_BLOCK_ADDRESS
DMX_FAIL_MODE
DMX_STARTUP_MODE
SENSOR_DEFINITION
Sensors SENSOR_VALUE
RECORD_SENSORS
DIMMER_INFO
MINIMUM_LEVEL
MAXIMUM_LEVEL
CURVE
Dimmer Settings CURVE_DESCRIPTION
OUTPUT_RESPONSE_TIME
OUTPUT_RESPONSE_TIME_ DESCRIPTION
MODULATION_FREQUENCY
MODULATION_FREQUENCY_ DESCRIPTION
Parameter
PROLIGHTS - Astra Profile900HQ
Value GET
0x0060 x
0x0070 x
0x0080 x
0x0081 x
0x0082 x
0x0090 x
0x00C0 x
0x00C1 x
0x00C2 x
0x00E0 x
0x00E1 x
0x00F0 x
0x0120 x
0x0121 x
0x0122 x
0x0140 x
0x0141 x
0x0142 x
0x0200 x
0x0201 x
0x0202
0x0340 x
0x0341 x
0x0342 x
0x0343 x
0x0344 x
0x0345 x
0x0346 x
0x0347 x
0x0348 x
SET
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
