5 - CONNECTION TO THE MAINS SUPPLY
WARNING: For protection from electric shock, the fixture must be earthed!
The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts (max absolutes range : 90- 264V).
If you need to install a power plug on the power cable to allow connection to power outlets, install a
grounding-type (earthed) plug, following the plug manufacturer's instructions. If you have any doubts
about proper installation, consult a qualified electrician.
The max power consumption is 1250W.
Core (EU)
Brown
Blue
Yellow+green
6 - START UP
CONNECT AND DISCONNECT POWER FROM THE PRODUCT
To apply and disconnect power to the product:
• Check that the product is installed and secured as indicated in the Safety Informations, and that
personal safety will not be put at risk when the fixture lights up.
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).
• The product is then ready for its operations and can be controlled through the available input sig-
nals on board.
• To disconnect power from the product, disconnect the Mains from the socket.
08
Core (US)
Black
White
Green
PROLIGHTS - Astra Profile900HQ
Connection
Plug terminal marking
Live
Neutral
Earth
L
N
