16 - ERROR MESSAGES
The error is shown on the unit display. In the table below, the "ERROR SHOWED ON SCREEN" column
lists the possible errors, accompanied by a possible cause ("POSSIBLE" CAUSES "column).
The color of the error messages (listed in the "COLOR MESSAGES" column) is different for each board
it refers to ("PCB" column).
On page 33 you can see the location of the various pcb boards with their respective error colors.
ERROR SHOWED ON
SCREEN
[DISPLAY BATTERY
ERROR]
[POWER SUPPLY FAN
ERROR]
[BASE FAN 1 ERROR]
[BASE FAN 2 ERROR]
[PAN MOTOR ERROR]
[PAN LOCKED]
[TILT MOTOR ERROR]
[TILT LOCKED]
[PAN ENCODER ERROR]
[TILT ENCODER ERROR]
[PAN ERROR]
[TILT ERROR]
[PAN/TILT PCB ERROR]
POSSIBLE CAUSES
Recharge The battery on the display board, keeping the
product ON for some hours.
If the error still occurrs, the battery is faulty . Replace the
battery on the display board.
Blower for cooling the power supply failed
First of the blowers for cooling the base failed
Second of the blowers for cooling the base failed
This message will appear after the reset of the product if:
the PAN magnetic-indexing circuit detect a failure (sensor
failed or magnet is missing).
or the stepping motor is defective.
or its driving IC on the PCB is defective.
or the product is not located in the default position after the
reset of the fixture.
Pan is locked
This message will appear after the reset of the product if:
the TILT magnetic-indexing circuit detect a failure (sensor
failed or magnet is missing) .
or the stepping motor is defective.
or its driving IC on the PCB is defective.
or the product is not located in the default position after the
reset of the fixture.
Tilt is locked
Pan encoder not detecteld
Tilt encoder not detecteld
Pan sensor not detecteld
Tilt sensor not detecteld
Pan sensor not detecteld.
PROLIGHTS - Astra Profile900HQ
POSSIBLE PCB
WITH ANOMALY
1U
1U
1U
1U
1U
2U
2U
2U
2U
2U
2U
2U
2U
2U
