ProLights Astra Profile900HQ User Manual

ProLights Astra Profile900HQ User Manual

900w profile moving head, with 6000k high quality white led source, 5 - 52 zoom
Hide thumbs

Advertisement

Quick Links

Download this manual
Astra Profile900HQ
900W Profile Moving head, with 6000K high
quality white LED source, 5° - 52° zoom
USER MANUAL
English version
Rev.01 - 01/25

Advertisement

loading
Need help?

Need help?

Do you have a question about the Astra Profile900HQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProLights Astra Profile900HQ

Summary of Contents for ProLights Astra Profile900HQ

  • Page 1 Astra Profile900HQ 900W Profile Moving head, with 6000K high quality white LED source, 5° - 52° zoom USER MANUAL English version Rev.01 - 01/25...
  • Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
  • Page 3 UPDATE LINKED FIXTURES - ALL FIXTURES ..............49 21 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............50 REPLACING THE FUSE ....................50 VISUAL CHECK OF PRODUCT HOUSING ..............50 RESETTING THE MAINTENANCE TIME MESSAGE ............51 PROLIGHTS - Astra Profile900HQ...
  • Page 4 • Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center.
  • Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
  • Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - Astra Profile900HQ...
  • Page 7 Check the updated accessories list, description and informations of the product at the following link: https://www.prolights.it/product/ASTRAPROFILE900HQ#accessories 2 - TECHNICAL DRAWING 150 [5.9] 150 [5.9] 297 [11.7] Ø728 [28.7] 445 [17.5] 310 [12.2] 648 [25.5] 115 [4.5] 516 [20.3] 180 [7.1] Fig. 01 Weight: 44,2 kg - 97,44 lbs PROLIGHTS - Astra Profile900HQ...
  • Page 8 3 - PAN AND TILT LOCK PAN Mechanism lock and release LOCK UNLOCK TILT Mechanism lock and release LOCK UNLOCK Fig. 02 PROLIGHTS - Astra Profile900HQ...
  • Page 9 Do not use any type of clamp that does not completely encircle the structure when fastened. NOTE: Bracket-mounting is not allowed for ASTRAPROFILE900HQ. C6001 clamp Steel security cable OS30 PLUS  150 [5.9] 150 [5.9] Fig.03 PROLIGHTS - Astra Profile900HQ...
  • Page 10 • Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - Astra Profile900HQ...
  • Page 11 5. DMX IN/OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C. 6. POWER IN: for connection to the Mains 100-240V~/50-60Hz. 7. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (T15A 250V). 8. SAFETY EYES: to attach safety cable. Fig 04 PROLIGHTS - Astra Profile900HQ...
  • Page 12 ... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 06 - Example 46 DMX channels configuration PROLIGHTS - Astra Profile900HQ...
  • Page 13 2. Reach the addressing menu, then select the DMX ADDRESS settings. 3. Select the address from 1 to 512 using the navigation arrows/buttons and confirm by pressing ENTER. 4. Press Menu to exit and return to the Home screen. PROLIGHTS - Astra Profile900HQ...
  • Page 14 • Switch on the display using backup battery. Hold for 5s. • Switch off display by pressing button 4 for 5s while on being on Home screen. • USB port for Firmware Upgrade. PROLIGHTS - Astra Profile900HQ...
  • Page 15 YELLOW shows the one set on the TX GREEN EMERALD OCEAN BLUE DEEP PURPLE COOL WHITE LINK STRENGTH ** % Show Wireless quality by percentage CRMX SOFTWARE TimoFX: Vx.x.xx Show firmware version of TimoFX VERSION module PROLIGHTS - Astra Profile900HQ...
  • Page 16 Make fixture goes blackout OFF while BLACKOUT moving. FAST PAN/TILT MODE To choose the horizontal/ vertical move- ment speed. SYNC mode will sync move- MEDIUM ment speed with the whole ASTRAWASH f miliy fixtures. SLOW HOME POSITION STANDARD CUSTOM PROLIGHTS - Astra Profile900HQ...
  • Page 17 Transfer settings from the current fixture WITHOUT DMX ADDRESS SETTINGS to another fixture of the same model using the DMX protocol. If a signal from another source is present, the Transfer Configuration function will not be WITH DMX ADDRESS available. PROLIGHTS - Astra Profile900HQ...
  • Page 18 PRISM 2 PRISM 2 ROTATION FROST 1 FROST 2 IRIS ZOOM FOCUS ANIMATION ANIMATION ROTATION BLADE 1 POSITON BLADE 1 ROT … BLADE 4 POSITON BLADE 4 ROT FRAME ROT PLATE 1 PLATE 1 PLATE 1+2 BEAM PROLIGHTS - Astra Profile900HQ...
  • Page 19 ANIMATION ROTATION BLADE 1 POSITON BLADE 1 ROT … BLADE 4 POSITON BLADE 4 ROT FRAME ROT CONTROL FACTORY BASIC RELOAD Default of all parameters excepted RELOAD Calibration FACTORY RELOAD YES Delete all USER PRESETS stored PROLIGHTS - Astra Profile900HQ...
  • Page 20 ERROR Show error message MESSAGE DEVICE LABEL Show RDM Label. ASTRAPROFILE900 DEVICE MODEL ASTRAPROFILE900 Show RDM fixture model RDM UID Show RDM UID of the fixture. SOFTWARE Show firmware version of the fixture 1U01 V1.0.00... VERSION PROLIGHTS - Astra Profile900HQ...
  • Page 21 3. SQUARE LAW - Light intensity is finer at low levels and becomes coarser at higher levels. 4. INVERSE SQUARE LAW - Light intensity is coarser at low levels and finer at higher levels. LINEAR S-CURVE DMX % DMX % SQUARE LAW INVERSE SQUARE LAW DMX % DMX % PROLIGHTS - Astra Profile900HQ...
  • Page 22 220 + PAN FINE This Reload also reset DMX address and mode. This CHANNEL SET TO 255, Basic Reload combination need to be performed while fixture is within 3s PAN FINE need resetting to be set to 0 PROLIGHTS - Astra Profile900HQ...
  • Page 23 0x0122 DMX_BLOCK_ADDRESS 0x0140 DMX_FAIL_MODE 0x0141 DMX_STARTUP_MODE 0x0142 SENSOR_DEFINITION 0x0200 Sensors SENSOR_VALUE 0x0201 RECORD_SENSORS 0x0202 DIMMER_INFO 0x0340 MINIMUM_LEVEL 0x0341 MAXIMUM_LEVEL 0x0342 CURVE 0x0343 Dimmer Settings CURVE_DESCRIPTION 0x0344 OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 PROLIGHTS - Astra Profile900HQ...
  • Page 24 0x0641 LOCK_STATE_DESCRIPTION 0x0642 IPV4_CURRENT_ADDRESS 0x0705 IP & DNS Configuration IPV4_STATIC_ADDRESS 0x0706 IDENTIFY_DEVICE 0x1000 RESET_DEVICE 0x1001 POWER_STATE 0x1010 PERFORM_SELFTEST 0x1020 SELF_TEST_DESCRIPTION 0x1021 CAPTURE_PRESET 0x1030 Control PRESET_PLAYBACK 0x1031 IDENTIFY_MODE 0x1040 PRESET_INFO 0x1041 PRESET_STATUS 0x1042 PRESET_MERGEMODE 0x1043 POWER_ON_SELF_TEST 0x1044 PROLIGHTS - Astra Profile900HQ...
  • Page 25 Parameter GET SET Value Description 0: Standard HOME_POSITION 0x8160 1: Custom CURRENT_HOURS 0x82C5 0-65535 0: No CLEAN_ALL_DATA 0x82C8 1: Yes 0: Hold DMX_FAULT 0x82DD 1: Blackout MAINTENANCE_T_ALERT_PERIOD 0x82DF MAINTENANCE_T_ELAPSED_TIME 0x82E0 ERROR_MESSAGE 0x82EA POWER_CONSUMPTION 0x82EF WIRELESS_QUALITY 0x82F4 PROLIGHTS - Astra Profile900HQ...
  • Page 26 Tilt = 128 Tilt = 255 Tilt movement range: 270° Pan movement range: 540° Pan = 0 Pan = 128 Pan = 255 Tilt = 42 Tilt = 42 Tilt = 42 Display Display Display Fig. 09 PROLIGHTS - Astra Profile900HQ...
  • Page 27 Fixture with CUSTOM HOME POSITION STANDARD HOME POSITION and PAN/TILT channels @ and PAN/TILT channels @ PAN @50% - DMX128 PAN @50% - DMX 172 TILT @ 84% - DMX 214 TILT @ 84% - DMX 214 PROLIGHTS - Astra Profile900HQ...
  • Page 28 Blade 4 position Rot Gobo Wheel 2 Blade 4 swivelling Gobo Rot 2 Frame rotation Gobo Rot Fine 2 Frame macros Prism 1 Frame macros speed Prism 1 Index/Rotation Autofocus Prism 2 Control Prism 2 Index/Rotation PROLIGHTS - Astra Profile900HQ...
  • Page 29 Open + Red Red + 5600K 5600K 5600K + Magenta Magenta Magenta + Green Color Wheel Green Green + Dark Orange Dark Orange Dark Orange + Dark Blue Dark Blue Dark Blue + Open Open Color Slot Open PROLIGHTS - Astra Profile900HQ...
  • Page 30 GOBO 2 GOBO 3 GOBO 4 GOBO 5 GOBO 6 GOBO 7 Gobo shaking - Slow to fast (Index on next channel) GOBO 1 GOBO 2 GOBO 3 GOBO 4 GOBO 5 GOBO 6 GOBO 7 PROLIGHTS - Astra Profile900HQ...
  • Page 31 Rot Gobo Wheel 2 GOBO 3 GOBO 4 GOBO 5 GOBO 6 GOBO 7 Gobo shaking - Slow to fast (Index on next channel) GOBO 1 GOBO 2 GOBO 3 GOBO 4 GOBO 5 GOBO 6 GOBO 7 PROLIGHTS - Astra Profile900HQ...
  • Page 32 Prism 2 Index/ Prism No Rotation Rotation Prism forward rotation fast to slow Prism No Rotation Prism backwards rotation slow to fast Light Frost Linear insertion 0 – 100% Heavy Frost Linear insertion 0 – 100% PROLIGHTS - Astra Profile900HQ...
  • Page 33 Blade 4 position Movement from outward to inward Swivelling from -30° towards 0° Blade 4 swivelling 0 degrees Swivelling from 0° towards +30° -45 degrees to 0 degrees Frame rotation 0 degrees 0 degrees to +45 degrees PROLIGHTS - Astra Profile900HQ...
  • Page 34 Macro 19 Macro 20 Macro 21 Macro 22 Macro 23 Macro 24 Macro 25 Macro 26 Macro 27 Macro 28 Macro 29 Macro 30 Macro 31 Macro 32 Macro 33 Macro 34 Macro 35 Macro 36 PROLIGHTS - Astra Profile900HQ...
  • Page 35 ROTATING GOBO WHEEL BLACKOUT OFF (index) ROTATING GOBO WHEEL CONTINUOUS MOVEMENT (index) ROTATING GOBO WHEEL STEP MOVE- MENT (index) DISPLAY ON DISPLAY 10S DISPLAY 20S DISPLAY 30S FLIP DISPLAY ON FLIP DISPLAY OFF FLIP DISPLAY AUTO PROLIGHTS - Astra Profile900HQ...
  • Page 36 LED FREQUENCY 50KHZ INVERT ZOOM OFF INVERT ZOOM ON RESET ALL RESET PAN RESET TILT RESET PAN & TILT RESET CYAN RESET MAGENTA RESET YELLOW RESET CTO RESET COLOR WHEEL RESET GOBO WHEEL 1 RESET GOBO ROTATION 1 PROLIGHTS - Astra Profile900HQ...
  • Page 37 RESET BLADE 1 ROT RESET BLADE 2 POSITON RESET BLADE 2 ROT RESET BLADE 3 POSITON RESET BLADE 3 ROT RESET BLADE 4 POSITON RESET BLADE 4 ROT RESET FRAME ROT Reserved FACTORY DEFAULT OF CONTROL FUNC- TIONS Reserved PROLIGHTS - Astra Profile900HQ...
  • Page 38 • Thinckness= up to 3 mm Up to 3 mm OD = Ø30 mm [1.2 in] [0.12 in] Gobo wheel 1 - Bottom (near the animation wheel) ATTENTION! Load with mirror surface toward the light source. Fig. 10 PROLIGHTS - Astra Profile900HQ...
  • Page 39 Gobo wheel 2 - Top (near the framing system) ATTENTION! Load with mirror surface toward the light source. Fig. 11 PROLIGHTS - Astra Profile900HQ...
  • Page 40 15 - COLOR WHEEL DARK BLUE DARK HIGH CRI ORANGE GREEN MAGENTA Fig. 12 PROLIGHTS - Astra Profile900HQ...
  • Page 41 Tilt is locked [PAN ENCODER ERROR] Pan encoder not detecteld [TILT ENCODER ERROR] Tilt encoder not detecteld [PAN ERROR] Pan sensor not detecteld [TILT ERROR] Tilt sensor not detecteld [PAN/TILT PCB ERROR] Pan sensor not detecteld. PROLIGHTS - Astra Profile900HQ...
  • Page 42 ROT. ERROR] position [GOBO FAN ERROR] Blower for cooling the GOBO wheel failed Failure detected during the reset of the color wheel, if this [COLOR WHEEL ERROR] wheel is not located in the default position PROLIGHTS - Astra Profile900HQ...
  • Page 43 Failure detected during the reset of the FROST, if the focus [FROST ERROR] lens is not located in its default position. Failure detected during the reset of the IRIS, if the focus [IRIS ERROR] lens is not located in its default position. PROLIGHTS - Astra Profile900HQ...
  • Page 44 IDENTIFICATION OF ELECTRONIC BOARDS 7U PCB 5U PCB 4U PCB 2U PCB 6U PCB LED DRIVER 3U PCB 1U PCB Fig. 13 PROLIGHTS - Astra Profile900HQ...
  • Page 45 AND TILT LOCK" paragraph (pag. 6). Loosen and remove the marked screws and opening the head covers (1) from both sides. Unclip the safety cable on both sides (2). Fig. 14 PROLIGHTS - Astra Profile900HQ...
  • Page 46 Gently remove the gobo holder from the gobo wheel (3, 4). Remove the spring and the gobo (5, 6). NOTE: the mirrored part of the gobo must be placed in the direction of the LED Source Fig. 15 PROLIGHTS - Astra Profile900HQ...
  • Page 47 • Disconnect the two connectors, power and serial bus plugs (marked A in drawing 2.1); • Unscrew the two screws marked in the front view (marked B in drawing 2.2); • Remove the plate with gobo wheels raising it up (C) and then pulling out (D) (drawing 2.2). Fig. 16 PROLIGHTS - Astra Profile900HQ...
  • Page 48 • Disconnect the two connectors, power and serial bus plugs (marked A in drawing 3.1); • Unscrew the two screws marked in the front view (marked B in drawing 3.1); • Pull out the plate with CMY Module (drawing 3.2); PROLIGHTS - Astra Profile900HQ...
  • Page 49 • Select the files to be updated. To select the desired files, move with the UP and DOWN buttons and select the file by pressing ENTER (Figure 2); • The selected files will be shown with a yellow square, select "NEXT" pressing RIGHT button, then press ENTER to confirm. (Figure 2) PROLIGHTS - Astra Profile900HQ...
  • Page 50 "START" pressing RIGHT button, then press ENTER to confirm. (Figure 1); • A screen with the progress of the update will appear (Figure 2), once update is completed the fixture will restart automatically and the update will be completed. PROLIGHTS - Astra Profile900HQ...
  • Page 51 UPDATE LINKED FIXTURES - ALL FIXTURES It is possible to update several Prolights fixtures from the Astra and Jet series at the same time. SELECT UPDATE DO NOT POWER OFF THIS FIXTURE Path: \FOLDER 2 LINKED FIXTURES ALL FIXTURES Progress:...
  • Page 52 WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel.
  • Page 53 • Check if the Fuse is intact and eventually replace it if fault necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in...
  • Page 54 Note...
  • Page 56 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
