ProLights Astra Profile900HQ User Manual page 29

Channel
Name
STANDARD
1 Pan
2 Pan fine
3 Tilt
4 Tilt fine
5 Dimmer
6 Dimmer Fine
7 Shutter
8 Cyan
9 Magenta
10 Yellow
11 CTO
12 Color Wheel
Function
Lineary from 0% to 100%
Lineary from 0% to 100%
Lineary from 0% to 100%
Lineary from 0% to 100%
Lineary from close to open
Lineary from close to open
Open
Strobe from slow to fast
Open
Pulse in from slow to fast
Close
Pulse out from slow to fast
Open
Randon from slow to fast
Open
Linear saturation 0 – 100%
Linear saturation 0 – 100%
Linear saturation 0 – 100%
Linear saturation 7000K to 2700K
Open
Open + Red
Red
Red + 5600K
5600K
5600K + Magenta
Magenta
Magenta + Green
Green
Green + Dark Orange
Dark Orange
Dark Orange + Dark Blue
Dark Blue
Dark Blue + Open
Open
Open
PROLIGHTS - Astra Profile900HQ
Color Positioning
Color Slot
Min Max
Default
DMX DMX
0 255 128
0 255 128
0 255 128
0 255 128
0 255 000
0 255 000
0 1
2 62
63 64
65 125
126 127 255
128 188
189 190
191 251
252 255
0 255 000
0 255 000
0 255 000
0 255 000
0
1 21
22
23 43
44
45 65
66
67 87
000
88
89 109
110
111 131
132
133 153
154 159
160 164
