9 - CONTROL PANEL
The product has a display and buttons for access to the control panel functions.
DISPLAY AND BUTTONS LAYOUT
The product has a display and buttons for access to the control panel functions:
1
5
4
3
12
• Browse upwards through the menu list and increases
1
• Scroll from left to right when entering numerical val-
2
2 • Browse downwards through the menu list and de-
3
• Return to the top level, or scroll from right to left
4
• Used to confirm the displayed value, or activate the
5
• Switch on the display using backup battery. Hold for 5s.
• Switch off display by pressing button 4 for 5s while on being on
Home screen.
• USB port for Firmware Upgrade.
PROLIGHTS - Astra Profile900HQ
the numeric value displayed.
ues, switching between hundreds, tens and units
creases the numeric value displayed.
when entering numerical values, switching between
units, tens and hundreds
displayed function or to access the menu tree or to
return a previous menu window.
Fig. 08
