Col
Gray
or
Yellow & Black
Cod
Blue & Green
es
Black Arrow
Green Arrow
Gray Arrow
User Manual
Plane is configured but disabled (A)
Normal Plane (B)
Trigger Plane (C)
The side of the plane the tool and/or elbow is allowed to be on (For
Normal Planes)
The side of the plane the tool and/or elbow is allowed to be on (For
Trigger Planes)
The side of the plane the tool and/or elbow is allowed to be on (For
Disabled Planes)
152
UR30
