2.1. Technical Specifications UR30
Robot type
Maximum payload
Reach
Degrees of freedom
Programming
Power consumption (average)
Ambient temperature range
Safety functions
IP classification
Cleanroom classification
Noise
Tool I/O ports
Tool I/O power supply & voltage
Force Torque sensor accuracy
Speed
Pose repeatability
Joint ranges
Footprint
Materials
Robot weight
System update frequency
Control Box size (W × H × D)
Control Box weight
Control Box I/O ports
Control Box I/O power supply
Communication
Control Box power source
Short-Circuit Current Rating (SCCR)
TP size (W × H × D)
TP weight
TP cable: Teach Pendant to Control Box
Robot Cable: robot arm to Control Box
UR30
UR30
30 kg (66.1 lb)
35 kg (77.1 lb) with boundary conditions according to the
manual
1300 mm / 51.18 in
6 rotating joints
PolyScope GUI on 12 in touchscreen
750 W (max.)
Approx. 300 W using a typical program
0-50 °C. At ambient temperatures above 35°C, the robot
may operate at reduced speed and performance.
17 sophisticated safety functions.
PLd Category 3 in accordance with: EN ISO 13849-1.
Robot Arm: IP65, Control Box: IP44, Teach Pendant: IP54
Robot Arm: ISO Class 4, Control Box: ISO Class 4, Teach
Pendant: ISO Class 1
Robot Arm: less than 65 dB(A), Control Box: less than 50 dB
(A)
2 digital in, 2 digital out, 2 analog in
2 A (Dual pin) 1 A (Single pin) & 12 V/24 V
10 N
All wrist joints: Max 210 °/s
Elbow joint: Max 150 °/s
Base and Shoulder joints: Max 120 °/s
Tool: Approx. 2 m/s / Approx. 78.7 in/s
± 0.1 mm / ± 0.0039 in (3.9 mils) per ISO 9283
± 360 ° for all joints
Ø245 mm / 9.65 in
Aluminium, PC/ASA plastic, steel
63.5 kg / 140 lb
500 Hz
460 mm x 449 mm x 254mm / 18.2 in x 17.6 in x 10 in
12 kg / 26.5 lb
16 digital in, 16 digital out, 2 analog in, 2 analog out
24 V/2 A
MODBUS TCP & EthernetNet/IP adapter, PROFINET,
USB 2.0, USB 3.0
100-240 VAC, 47-440 Hz
200A
300 mm x 231 mm x 50 mm
1.8 kg / 3.961 lb
4.5 m / 177 in
Hiflex (PUR) 6 m / 236 in x 12.1 mm
17
