Canon imagePROGRAF iPF670 Service Manual page 280

Chapter 7
15) MEDIASIZE2 CUT: Counters related to cut sheet printing
Display
D-SQ 24-36
D-SQ 17-24
D-SQ -17
D-CNT 24-36
D-CNT 17-24
D-CNT -17
16) HEAD DOT CNT.1: Counter related to dot count
Display
XX
TTL
17) HEAD DOT CNT.2: Counter related to dot count
Display
XX
TTL
7-24
Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (data size)
Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (data size)
Cumulative print area of paper less than 17 inches (data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(data size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(data size)
Cumulative number of sheets of A4-equivalent paper less than 17 inches (data size)
XX: Ink color
Dot counts of each colors of the currently installed printhead
Total dot counts of each colors of the currently installed printhead
XX: Ink color
Cumulative dot counts of each colors
Total cumulative dot counts of each colors
Description
Description
Description
Unit
Sq.m/Sq.f
Sq.m/Sq.f
Sq.m/Sq.f
sheets
sheets
sheets
Unit
(x 1,000,000) dots
(x 1,000,000) dots
Unit
(x 1,000,000) dots
(x 1,000,000) dots
