4. Contact between Pinch Roller Release Shaft and Pinch Roller [1] / Pinch Roller Pressure Release Gear [2] / Protrusion of Release lever [3] / Bushing of Feed

Roller [4]

[1]

[2]

[4]

[3]

F-4-120

4-58
