Chapter 2

2.5.2 Ink passage system

Air Passage Valve Open/Closed

Detection Sensor (L)/(R)

Ink Detection Sensor (L)/(R)

2-48

Head Management Sensor

Pump Encoder Sensor

Ink Supply Valve Open/Closed

Detection Sensor (L)/(R)

Shutter HP Sensor

F-2-37

Pump Cam Sensor

0023-2556
