13. INSTALLATION AND WIRING

13. INSTALLATION AND WIRING
NOTE! Screen wire termination is not provided.
EBL512 G3
J3
For connection to a separate presentation
system when the Gateway function is used
1.
2. RxD
3. TxD
4.
5. GND
6.
7. RTS
8. CTS
9.
TECHNICAL DESCRIPTION 1598 • DOCUMENT NUMBER: MEW01930 • REVISION: 4
0.65 m cable, supplied with the web-server
Brown
Blue
Green
0.65 m cable, supplied with the web-server
Yellow
Green
Black
For connection to Local Area Network
1. TX+
2. TX-
3. RX+
4.
5.
6. RX-
7.
8.
51
Brown
Blue
Green
EMI filter
Yellow
Green
Black
Power supply
Male, MOLEX
Type KK, 3.5
Modem COM
(RS232C)
(Serial port Male
9-pin connection)
PLC COM
(RS232C)
Ethernet COM
