10. EBLWEB

10.7.2. E-MAIL ADDRESS

The e-mail handling in EBLWeb handles six different types of e-mails. Each e-mail type can be disabled.
See 4.6.1.2. The EBLWin configured e-mail addresses for recipients are shown in this tab page. Each e-
mail address shown has a button to send a test mail to the configured e-mail address.

10.8. CONTROL UNIT

Press the Control unit button to access the control unit list view.
This page show all control units in the EBL-system. Each control unit row has a colored sign for
synchronization status.
BLACK Not connected.
■
RED Synchronization has not started.
■
YELLOW Synchronization is in progress.
■
GREEN Synchronization is finished.
■
Which control unit should be monitored and be included in synchronization is determined by the SSD from
EBLWin. Those control units that are included according to SSD, will have buttons for Control unit
statistics (Sys.info.) and Loop statistics.

10.8.1. CONTROL UNIT STATISTICS (SYSTEM INFORMATION)

This page shows the system information of selected CU and consists of momentary statistics data asked
from the connected CU.
The current consumption for rectifier, current consumption for charger, battery temperature, low
capacity voltage difference, site name (also time of SSD download) and software version for the CU is
displayed.

10.8.2. LOOP STATISTICS

This page shows the COM loop statistics for communication in selected CU.
