Development Tools
For rapid product development and to simplify device parameter setting, Holtek has provided
relevant development tools which users can download from the following link:
https://www.holtek.com/page/detail/dev_plat/Touch_Workshop
General Description
The series of devices are A/D Flash Memory type 8-bit high performance RISC architecture
microcontrollers with fully integrated touch key functions. With all touch key functions provided
internally and with the convenience of Flash Memory multi-programming features, each device has
all the features to offer designers a reliable and easy means of implementing touch keys within their
products applications.
In addition to the Flash program memory, other memory includes an area of RAM Data Memory as
well as an area of true EEPROM memory for storage of non-volatile data such as serial numbers,
calibration data etc. Analog feature includes a multi-channel 12-bit A/D converter. Protective
features such as an internal Watchdog Timer, Low Voltage Reset and Low Voltage Detector coupled
with excellent noise immunity and ESD protection ensure that reliable operation is maintained in
hostile electrical environments.
A full choice of external and internal, high and low speed oscillators are provided and can be
flexibly used for different applications. The ability to operate and switch dynamically between
a range of operating modes using different clock sources gives users the ability to optimise
microcontroller operation and minimise power consumption. Easy communication with the outside
world is provided using the internal SPI, I
I/O programming features, Time Base functions, Timer Modules and many other features further
enhance device functionality and flexibility.
The touch key devices will find excellent use in a huge range of modern Touch Key product
applications such as remote control, instrumentation, household appliances such as electric rice
cookers and electronically controlled tools to name but a few.
Selection Table
Most features are common to all devices. The main features distinguishing them are Memory
capacity, I/O count, Touch Module and key mumber, stack capacity and package types. The
following table summarises the main features of each device.
Part No.
BS66F340C
BS66F350C
BS66F360C
Part No.
BS66F340C
BS66F350C
BS66F360C
Note: As devices exist in more than one package format, the table reflects the situation for the
package with the most pins.
Rev. 1.11
BS66F340C/BS66F350C/BS66F360C
C and UART interfaces, while the inclusion of flexible
2
Program Data Data
Memory Memory EEPROM
4K×16 512×8
8K×16 768×8 128×8
16K×16 1024×8
Touch Touch
Timer Module
Module Key
3 12
10-bit CTM×2
10-bit PTM×1 5 20
16-bit STM×1
7 28
8
Touch A/D Flash MCU
External
I/O A/D
Interrupt
26
40 2 12-bit×8
46
SIM UART Stacks
√ √ 8
√ √ 8 44/48LQFP
√ √ 12 44/48LQFP
November 09, 2023
Time Base
2
Package
28SSOP
