• PANS Register – BS66F340C
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 PANS5: PA5 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 4~3 Unimplemented, read as "0"
Bit 2 PANS2: PA2 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 1 PANS1: PA1 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 0 PANS0: PA0 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
• PANS Register – BS66F350C/BS66F360C
Bit 7
Name PANS7
R/W R/W
POR 0
Bit 7 PANS7: PA7 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 6 PANS6: PA6 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 5 PANS5: PA5 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 4~2 Unimplemented, read as "0"
Bit 1 PANS1: PA1 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
Bit 0 Unimplemented, read as "0"
• PENS Register – BS66F340C
Bit 7
Name —
R/W —
POR —
Bit 7~4 Unimplemented, read as "0"
Bit 3 PENS3: PE3 sink current selection (NMOS adjust)
0: Sink current = Level 0 (Min.)
1: Sink current = Level 1 (Max.)
