The most important point to note is to make sure that the desired pin-shared function is properly
selected and also deselected. For most pin-shared functions, to select the desired pin-shared function,
the pin-shared function should first be correctly selected using the corresponding pin-shared control
register. After that the corresponding peripheral functional setting should be configured and then the
peripheral function can be enabled. However, a special point must be noted for digital input pins,
such as INTn, xTCKn, xTPnI, etc, which share the same pin-shared control configuration with their
corresponding general purpose I/O functions when setting the relevant pin-shared control bits. To
select these pin functions, in addition to the necessary pin-shared control and peripheral functional
setup aforementioned, they must also be set as an input by setting the corresponding bit in the I/O
port control register. To correctly deselect the pin-shared function, the peripheral function should
first be disabled and then the corresponding pin-shared function control register can be modified to
select other pin-shared functions.
Register
Name
7
IFS0 —
IFS1 —
PAS0 PAS07
PAS1 PAS17
PBS0 PBS07
PBS1 PBS17
PCS0 PCS07
PES0 PES07
PES1 —
Register
Name
7
IFS0 —
IFS1 —
PAS0 PAS07
PAS1 PAS17
PBS0 PBS07
PBS1 PBS17
PCS0 PCS07
PCS1 PCS17
PDS0 PDS07
PDS1 PDS17
PES0 PES07
PES1 PES17
Register
Name
7
IFS0 —
IFS1 —
PAS0 PAS07
PAS1 —
PBS0 PBS07
PBS1 PBS17
Rev. 1.11
6 5 4
— IFS05 IFS04
— IFS15 IFS14
PAS06 PAS05 PAS04
PAS16 — —
PBS06 PBS05 PBS04
PBS16 PBS15 PBS14
PCS06 PCS05 PCS04
PES06 PES05 PES04
— — —
Pin-shared Function Selection Register List – BS66F340C
6 5 4
— IFS05 IFS04
— IFS15 IFS14
PAS06 PAS05 PAS04
PAS16 PAS15 PAS14
PBS06 PBS05 PBS04
PBS16 PBS15 PBS14
PCS06 PCS05 PCS04
PCS16 PCS15 PCS14
PDS06 PDS05 PDS04
PDS16 PDS15 PDS14
PES06 PES05 PES04
PES16 PES15 PES14
Pin-shared Function Selection Register List – BS66F350C
6 5 4
— IFS05 IFS04
— IFS15 IFS14
PAS06 PAS05 PAS04
— — —
PBS06 PBS05 PBS04
PBS16 PBS15 PBS14
103
Bit
3 2 1
IFS03 IFS02 IFS01
IFS13 IFS12 IFS11
PAS03 PAS02 PAS01
PAS13 PAS12 PAS11
PBS03 PBS02 PBS01
PBS13 PBS12 PBS11
PCS03 PCS02 PCS01
PES03 PES02 PES01
PES13 PES12 PES11
Bit
3 2 1
IFS03 IFS02 IFS01
IFS13 IFS12 IFS11
PAS03 PAS02 PAS01
PAS13 PAS12 PAS11
PBS03 PBS02 PBS01
PBS13 PBS12 PBS11
PCS03 PCS02 PCS01
PCS13 PCS12 PCS11
PDS03 PDS02 PDS01
PDS13 PDS12 PDS11
— — —
PES13 PES12 PES11
Bit
3 2 1
IFS03 IFS02 IFS01
IFS13 IFS12 IFS11
PAS03 PAS02 PAS01
PAS13 PAS12 PAS11
PBS03 PBS02 PBS01
PBS13 PBS12 PBS11
