Holtek BS66F340C Manual page 114

• PES1 Register – BS66F350C
Bit 7
Name PES17
R/W R/W
POR 0
Bit 7~6 PES17~PES16: PE7 Pin-Shared function selection
00: PE7
01: CTP1B
10: PE7
11: PE7
Bit 5~4 PES15~PES14: PE6 Pin-Shared function selection
00: PE6
01: CTP1
10: PE6
11: PE6
Bit 3~2 PES13~PES12: PE5 Pin-Shared function selection
00: PE5/CTCK1
01: PE5/CTCK1
10: OSC2
11: PE5/CTCK1
PES11~PES10: PE4 Pin-Shared function selection
Bit 1~0
00: PE4
01: PE4
10: OSC1
11: PE4
• PES1 Register – BS66F360C
Bit 7
Name PES17
R/W R/W
POR 0
PES17~PES16: PE7 Pin-Shared function selection
Bit 7~6
00: PE7
01: CTP1B
10: KEY26
11: PE7
PES15~PES14: PE6 Pin-Shared function selection
Bit 5~4
00: PE6
01: CTP1
10: KEY25
11: PE6
Bit 3~2 PES13~PES12: PE5 Pin-Shared function selection
00: PE5/CTCK1
01: PE5/CTCK1
10: OSC2
11: PE5/CTCK1
Bit 1~0 PES11~PES10: PE4 Pin-Shared function selection
00: PE4
01: PE4
10: OSC1
11: PE4
Rev. 1.11
BS66F340C/BS66F350C/BS66F360C
6 5 4
PES16 PES15 PES14
R/W R/W R/W
0 0 0
6 5 4
PES16 PES15 PES14
R/W R/W R/W
0 0 0
114
Touch A/D Flash MCU
3 2 1
PES13 PES12 PES11
R/W R/W R/W
0 0 0
3 2 1
PES13 PES12 PES11
R/W R/W R/W
0 0 0
November 09, 2023
0
PES10
R/W
0
0
PES10
R/W
0
