BS66F340C/BS66F350C/BS66F360C
Touch A/D Flash MCU
Register
Name
FC0 CFWEN
FC1
FC2
(BS66F350C/
BS66F360C)
FARL
FARH
(BS66F340C)
FARH
(BS66F350C)
FARH
(BS66F360C)
FD0L
FD0H
FD1L
FD1H
FD2L
FD2H
FD3L
FD3H
• FC0 Register
Bit 7
Name CFWEN
R/W R/W
POR 0
Bit 7 CFWEN: Flash Memory Erase/Write function enable control
0: Flash memory erase/write function is disabled
1: Flash memory erase/write function has been successfully enabled
When this bit is cleared to 0 by application program, the Flash memory erase/write
function is disabled. Note that this bit cannot be set high by application programs.
Writing a "1" into this bit will result in no action. This bit is used to indicate the Flash
memory erase/write function status. When this bit is set high by the hardware, it means
that the Flash memory erase/write function is enabled successfully. Otherwise, the
Flash memory erase/write function is disabled if the bit is zero.
FMOD2~FMOD0: Flash memory Mode selection
Bit 6~4
000: Write Mode
001: Block/Page Erase Mode
011: Read Mode
110: Flash memory Erase/Write function Enable Mode
Other values: Reserved
These bits are used to select the Flash Memory operation modes. Note that the "Flash
memory Erase/Write function Enable Mode" should first be successfully enabled
before the Erase or Write Flash memory operation is executed. When these bits are set
to "001", the "Block erase" mode is selected for BS66F340C while the "Page erase"
mode is selected for BS66F350C/BS66F360C.
Bit 3 FWPEN: Flash memory Erase/Write function enable procedure Trigger
0: Erase/Write function enable procedure is not triggered or procedure timer times out
1: Erase/Write function enable procedure is triggered and procedure timer starts to count
Rev. 1.11
7 6 5
FMOD2 FMOD1 FMOD0
D7 D6 D5
— — —
FA7 FA6 FA5
— — —
— — —
— — FA13
D7 D6 D5
D15 D14 D13
D7 D6 D5
D15 D14 D13
D7 D6 D5
D15 D14 D13
D7 D6 D5
D15 D14 D13
IAP Register List
6 5
FMOD2 FMOD1 FMOD0
R/W R/W R/W
0 0
43
Bit
4 3 2
FWPEN FWT
D4 D3 D2
— — —
FA4 FA3 FA2
— FA11 FA10
FA12 FA11 FA10
FA12 FA11 FA10
D4 D3 D2
D12 D11 D10
D4 D3 D2
D12 D11 D10
D4 D3 D2
D12 D11 D10
D4 D3 D2
D12 D11 D10
4 3 2
FWPEN FWT FRDEN
R/W R/W
0 0 0
1 0
FRDEN FRD
D1 D0
— CLWB
FA1 FA0
FA9 FA8
FA9 FA8
FA9 FA8
D1 D0
D9 D8
D1 D0
D9 D8
D1 D0
D9 D8
D1 D0
D9 D8
1 0
FRD
R/W R/W
0 0
