MARKING OF THE AIR INLET AND OUTLET OF THE AIR HANDLING UNIT
INSPECTION SIDE VIEW - RIGHT-HAND VERSION
MARKING OF THE AIR INLET AND OUTLET OF THE AIR HANDLING UNIT
INSPECTION SIDE VIEW - LEFT-HAND DESIGN
www.vtsgroup.com
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
RA
Exhaust air inlet.
FA
Fresh air intake
SA
Room supply air
outlet
EA
Exhaust air outlet
RA
Exhaust air inlet.
FA
Fresh air intake
SA
Room supply air
outlet
EA
Exhaust air outlet
8
