The MI Basic 2 HY allows active alarms to be viewed and cleared. If an alarm is present, the bell
symbol is shown on the main screen and the alarm number is displayed in place of the time.
The alarm is cancelled, once the cause of the alarm has been removed, by holding down
PROGRAMMING MODE
With the display switched off by holding down the button, hold down the button to enter the
programming mode (change of advanced parameters).
Subsequent presses of
is automatically exited after a moment of inactivity or by pressing
Paramete
Scope
r
IP 1-255
A1 2400/4800/9600
A2 0/1/2
A3 12/24
A4 00/01
A5 0-300
A6 -9,9...9,9
SPECIFICATION
Type of device
Temperature
measurement
Service
Communication
Power supply
Power consumption
Display
Design
Dimensions (H x W x
D)
Permissible operating
temperature
Destination
Assembly
Mass
www.vtsgroup.com
toggle through the parameters and use
Default
value
16 Modbus address
9600 Modbus - transmission speed
0 Modbus - parity bit (0 = none, 1 = even, 2 = odd)
24 Clock mode [h]
Temperature units (00 = ⁰C, 01 = ⁰F)
00
10 Screen backlight time [s]
Correction of the built-in temperature sensor [⁰C].
0
physical membrane keyboard keys
Modbus RTU (2400 / 4800 / 9600 bps)
for indoor mounting (IP20)
in a standard Ø60 installation box on a mounting bracket
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
to set their value. The menu
.
Description
control panel; regulator
0⁰C ... 70⁰C, 10k TC
110-230V AC
1.5 VA
backlit, graphic LCD
ABS + polyester
86 x 86 x 17 mm
0⁰C ... 50⁰C
150g
.
