! The equipment as well as its components should be:
•
stored in rooms with the following conditions:
o
o
•
protected from
as well as with any other chemical substances liable to have a corrosive effect on the
equipment or its accessories.
3.2 PREPARATION FOR INSTALLATION
Transport of the equipment requires lifting equipment at the installation site. Make sure that once the unit
is installed, there will be enough space to properly bring the technological and electrical installations to
the unit and to carry out maintenance on the unit without any problems.
3.2.1 LOCATION OF THE DEVICE
Allow adequate space for the placement of piping and electrical connections. All piping and ducting should
be fixed independently of the air handling unit to reduce excessive noise and vibration.
RECOMMENDATIONS FOR THE LOCATION OF THE DEVICE
The weight of the appliance must be taken into account. When doing so, refer to the weight of
the appliance on its rating plate. The weight on the rating plate does not take into account the
1
weight of the media (except R410A), which should be taken into account when installing the
unit.
Sufficient space should be left to allow for the removal of the enclosure panels and for access
2
for maintenance work.
3
The installer must provide a lifting device to raise the ceiling-mounted optional duct sections.
4
All equipment must be mounted horizontally.
Consideration should be given to the requirements for coil and drain pipework and condensate
5
drainage.
www.vtsgroup.com
relative humidity: φ < 80 %, at t = (+20) °C,
ambient temperature: (-40) °C < t < (+60) °C.
contact with corrosive
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
(caustic) dusts, gases or vapours,
