7.1 STANDARD EQUIPMENT WITH FACTORY-FITTED CONTROLS
ELEMENTS
STANDARD CONTROLS COMPONENTS - ASSEMBLY AND CONNECTION AT THE FACTORY
Designation
uPC3 controller
Terminal 1 (T1)
Security
B2 Temperature sensor
H2 Moisture sensor
B4 Temperature sensor
B6 Temperature sensor
B3 Temperature sensor
Differential pressure sensor
Differential pressure sensor
Differential pressure sensor
Differential pressure sensor
The sensors are mounted in the heat recovery section.
www.vtsgroup.com
Name
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
Location
Controls switchgear
Connection terminal for peripheral Controls
components
Controls switchgear
(according to the diagram)
Return air from the room
(extract before recovery)
Return air from the room
(extract before recovery)
Exhaust air
(exhaust after recovery)
Supply air
(for recovery)
Outside air
(before recovery)
Supply air (pre-filter)
Supply air (fan)
Exhaust air (pre-filter)
Exhaust air (fan)
