7 PLUG&PLAY CONTROLS COMPONENTS
The VENTUS COMPACT TOP base unit including hexagonal exchanger, fans and air filters and
optional water heater is supplied as a pre-wired unit with the configured Controls system
connected.
The Controls system is based on the factory-programmed and built-in uPC3 controller.
Peripheral Controls components whose specifics require installation outside the base unit (room
or duct mounted sensors, actuators, valves) are supplied in separate packages. It is necessary
to connect them on site according to the installation and connection instructions.
LABELLING OF PLUG&PLAY CONTROLS COMPONENTS
Controls components requiring connection
on site are equipped with connection cables
that include a label with the method of
connection to Terminal 1.
CONNECTIONS
„+" positive pressure side (red wire), "-" negative pressure side (blue wire),
www.vtsgroup.com OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
The basic configuration of the
VENTUS COMPACT with heat
recovery and heat pump is
supplied as a pre-wired unit with
a connected and configured
control system.
