REQUIREMENTS:
BT MODULE SUPPORT
The unit allows other units to connect via the broadcast system. The default name of the module by
which it broadcasts
with an unconfigured control panel number, the module reports as "AHU Bluetooth".
By default, the server only allows previously paired devices to connect, this status is indicated by an
off LED with a pulse on.
You can allow all devices to connect by holding down the pairing button for approximately 3 seconds.
The LED will then be on with the pulse off. The server can be connected to a maximum of one client
device at a time.
A server that is actively connected to another device has its LED constantly on.
LED STATES:
•
off - offline mode / no power,
•
disabled with pulse - server mode with the possibility of connecting new devices disabled,
•
enabled with pulse - server mode with connection of new devices enabled
•
enabled - server mode with active connection
•
The app includes a tutorial for pairing and connecting the device.
The mHMI smartphone application has been developed for service technicians as well as
for end users of VENTUS, VENTUS COMPACT and VENTUS COMPACT TOP air-handling units.
The app is available on: Play App Store and Apple App Store.
The application allows both the current change of settings and the detailed configuration of the
operating parameters of the air handling unit and its components. The intuitive interface makes it easy
to set up the basic functions of the control panel, making operation of the control panel a pleasure
even for a user with no previous experience.
www.vtsgroup.com
•
Controls software uPC3 from 1.0.26
•
Smartphone with systems from versions: Android 9, iOS 11
•
Assignment of rights and activation:
o location (linked to a Bluetooth connection)
o bluetooth connections
is the factory number
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
of the air handling unit. For devices
