FIXING OF THE FRAME/FOOTPLATE TO THE GROUND
CONDENSATE DRAINAGE
!
The dimensions of the base block and additional functions are available in the unit's technical
.
data sheet
www.vtsgroup.com
! When planning the foundation of the unit,
provision
condensate from the drip trays.
H [mm] = total fan discharge in mm water
column (Pa*0.1)
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
!
The frame should be
fixed through the
extreme holes in the
feet/frame.
!
must be made to
!
drain the
23
