7.3 CABLE STANDARDS
Fire alarm relay
Multifunction switch
Optional multifunction switch
Supply air temperature sensor
Room/extract air temperature sensor
Return water temperature sensor for water heater
Electric heater (HE) alarm relay
Air-side antifreeze thermostat to protect the water heater from freezing
Analogue controlled water heater valve
Electric heater power control input
Water heater circulation pump contactor
Alarm relay for refrigerator/cooling unit/heating pump
Refrigerator start-up input
Chiller start-up input - stage I
Chiller start-up input - stage II
Recirculation throttle actuator
Bypass actuator for the cross-flow exchanger
HMI Basic UPC control panel - interface with limited functionality
HMI Advanced UPC control panel - full-function interface
ID
Cables for the transmission of control
[1] signals - screened copper wires. PVC
insulation.
[2] Copper conductors PVC insulation
[3] Copper conductors PVC insulation
[4] Unshielded flat data cables.
www.vtsgroup.com
APPLICATION
TYPE
WIRED
OIMM VENTUS COMPACT HP - ver.5.0.9 (10.2024)
TYPE
WIRED
[2]
[2]
[2]
[1]
[1]
[1]
[2]
[2]
[1]
[1]
[2]
[2]
[2]
[2]
[1]
[1]
[3]
[4]
DESCRIPTION
Rated voltage 300/500 V. Ambient
temperature: 30 °C to 80 °C.
Rated voltage 450/750V. Ambient
temperature: -40 to 70 °C
Rated voltage 150 V.
Ambient temperature: - 20...60°C
Rated voltage 150 V.
Ambient temperature: - 20...60°C
WIRING [mm]
2x0,75
2x0,75
2x0,75
2x0,75
2x0,75
2x0,75
2x0,75
2x0,75
3x0,75
3x0,75
3x1,5
2x0,75
2x0,75
2x0,75
2x0,75
3x0,75
3x0,75
UTP 1x2
8x0,1
